Table 6 — Hilti HIT-HY 100 adhesive design strength with masonry / bond failure for threaded rod in the top of uncracked fully grouted CMU walls and installed at minimum edge distance parallel with masonry course 1 , 2 , 3 , 4 , 5 , 6 , 7 , 8
Nominal anchor diameter in .
1 / 2
5 / 8
3 / 4
Effective embedment in . ( mm ) f ́m = 1500 psi ( 10.3 MPa ) lb ( kN )
Tension ( lesser of breakout or bond ) — ΦN n
f ́m = 2000 psi ( 13.8 MPa ) lb ( kN ) f ́m = 2500 psi ( 17.2 MPa ) lb ( kN ) f ́m = 3000 psi ( 20.7 MPa ) lb ( kN ) f ́m = 1500 psi ( 10.3 MPa ) lb ( kN )
Shear ( lesser of pryout or crushing ) — ΦV n
f ́m = 2000 psi ( 13.8 MPa ) lb ( kN ) f ́m = 2500 psi ( 17.2 MPa ) lb ( kN ) f ́m = 3000 psi ( 20.7 MPa ) lb ( kN )
2-3 / 4
675
675
675
675
1,225
1,410
1,580
1,725
( 70 )
( 3.0 )
( 3.0 )
( 3.0 )
( 3.0 )
( 5.4 )
( 6.3 )
( 7.0 )
( 7.7 )
4-1 / 2
1,110
1,110
1,110
1,110
1,320
1,520
1,700
1,865
( 114 )
( 4.9 )
( 4.9 )
( 4.9 )
( 4.9 )
( 5.9 )
( 6.8 )
( 7.6 )
( 8.3 )
6-3 / 4
1,660
1,660
1,660
1,660
1,320
1,520
1,700
1,865
( 171 )
( 7.4 )
( 7.4 )
( 7.4 )
( 7.4 )
( 5.9 )
( 6.8 )
( 7.6 )
( 8.3 )
10
2,460
2,460
2,460
2,460
1,320
1,520
1,700
1,865
( 254 )
( 10.9 )
( 10.9 )
( 10.9 )
( 10.9 )
( 5.9 )
( 6.8 )
( 7.6 )
( 8.3 )
3-1 / 8
365
365
365
365
925
925
925
925
( 79 )
( 1.6 )
( 1.6 )
( 1.6 )
( 1.6 )
( 4.1 )
( 4.1 )
( 4.1 )
( 4.1 )
4-1 / 2
525
525
525
525
1,330
1,330
1,330
1,330
( 114 )
( 2.3 )
( 2.3 )
( 2.3 )
( 2.3 )
( 5.9 )
( 5.9 )
( 5.9 )
( 5.9 )
6-3 / 4
785
785
785
785
1,475
1,700
1,905
1,995
( 171 )
( 3.5 )
( 3.5 )
( 3.5 )
( 3.5 )
( 6.6 )
( 7.6 )
( 8.5 )
( 8.9 )
10
1,160
1,160
1,160
1,160
1,475
1,700
1,905
2,085
( 254 )
( 5.2 )
( 5.2 )
( 5.2 )
( 5.2 )
( 6.6 )
( 7.6 )
( 8.5 )
( 9.3 )
3-1 / 2
645
645
645
645
1,640
1,640
1,640
1,640
( 89 )
( 2.9 )
( 2.9 )
( 2.9 )
( 2.9 )
( 7.3 )
( 7.3 )
( 7.3 )
( 7.3 )
4-1 / 2
825
825
825
825
2,105
2,105
2,105
2,105
( 114 )
( 3.7 )
( 3.7 )
( 3.7 )
( 3.7 )
( 9.4 )
( 9.4 )
( 9.4 )
( 9.4 )
6-3 / 4
1,240
1,240
1,240
1,240
3,115
3,160
3,160
3,160
( 171 )
( 5.5 )
( 5.5 )
( 5.5 )
( 5.5 )
( 13.9 )
( 14.1 )
( 14.1 )
( 14.1 )
10
1,840
1,840
1,840
1,840
3,115
3,600
4,020
4,405
( 254 )
( 8.2 )
( 8.2 )
( 8.2 )
( 8.2 )
( 13.9 )
( 16.0 )
( 17.9 )
( 19.6 )
1 Linear interpolation between embedment depths and masonry compressive strengths is not permitted . 2 Tabular values are for a single anchor located at minimum edge of 1-3 / 4-in ( 2-3 / 4-in for 3 / 4-in diameter ) from edge parallel with masonry course with no additional influence from nearby edges or additional anchors . For designs with the additional influence of nearby edges , a different edge distance , or additional anchors , use Hilti PROFIS Engineering Design software or perform anchor calculation using design equations from AC58 . 3 Compare masonry tabular values to the steel values in the Appendix . The lesser of the values is to be used for the design . 4 Data is for Temperature Range A : Maximum short term temperature = 130 ° F ( 55 ° C ) | Maximum long term temperature = 110 ° F ( 43 ° C ).
For Temperature Range B : Maximum short term temperature = 176 ° F ( 80 ° C ) | Maximum long term temperature = 110 ° F ( 43 ° C ), multiply design strength values values by 0.91 . 5 Tabular values are for dry masonry conditions . For water saturated masonry conditions , multiply design strength values by :
1 / 2-in diameter - α sat
= 0.84 5 / 8-in and 3 / 4-in diameter - α sat
= 1.00 6 Tabular values are for static loads only . Seismic design is not permitted for uncracked masonry . 7 Tabular shear values are for shear force parallel to the edge parallel with the masonry course . For shear force perpendicular to the edge parallel with the masonry course , multiply design strength values in shear by the following reduction factors : 1 / 2-in and 5 / 8-in . diameter = 0.50 3 / 4-in diameter = 0.46
8 Tabular values are for short term loads only . For sustained loads including overhead use , see Section 3.0 .
