Backhoe
Excavators
Telescopic
Boom Lifts
Make JLG JLG JLG JLG JLG Manitou Manitou Manitou
Model 860SJ 1200SJP 1350SJP 1500SJ 1850SJ 220 TJ 260 TJ 280 TJ
Platform height (m) 26,21 36,73 41,3 45,72 56,56 19,77 25,75 25,75
Working height (m) 28,21 38,73 43,3 47,72 58,56 21,77 27,75 27,75
Platform size (m) 0,91 X 2,44 0,91 X 2,44 0,91 X 2,44 0,91 X 2,44 0,91 x 2,44 2,1 x 0,8 m 2,30 x 0,90 m 2,30 x 0,90 m
Horizontal outreach (m) 22,86 22,86 24,38 24,38 24,38 17,36 21,45 21,45
Platform capacity (kg) 230 230 230 230 230 230 350 350
Jib - overall length (m) 1,83 2,44 2,44 4,60 - 7,60 3,96 - 6,10 7,29 8,04 11,35
Jib - range of articulation (m) 130 (+70/-60) 130 (+75/-55) 130 (+75/-55) 120 (+75/-45) 120 (+75/-45) - - -
Overall width (m) 2,49 3,81 3,81 3,81 5,03 2,48 2,43 2,43
Tailswing - working condition (m) 1,42 1,68 1,68 1,68 2,31 - - -
Stowed height (m) 3,05 3,05 3,05 3,05 3,05 2,72 2,72 2,72
Stowed length (m) 12,19 13,67 14,89 18,82 19,46 7,29 8 8,04
Overall length (m) - 10,64 11,86 13,11 14,58 9,8 11,35 11,35
Wheel base (m) 3,05 3,81 3,81 3,81 4,57 2,8 2,8 2,8
Machine weight (kg) 17200 18500 20400 22000 27360 11850 16500 16500
Axle Oscillation (m) 0,2 0,3 0,3 0,3 0,3 1,76 9,27 9,75
Turning radius outside 2WS (m) 6,02 5,89 5,59 5,89 6,60 6,19 4,33 4,33
Turning radius inside 4WS (m) - - - - - 2,96 2 2
Make Deutz Deutz Deutz Deutz Deutz Kubota Kubota Kubota
Model TD 2.9 50.0
kW TCD 2.9 55.4
kW TCD 2.9 55.4
kW TCD 2.9 55.4
kW TCD 3.6 74.4
kW V1505.E3B
Stage 3A V2403-M V2403-M
South African distributor Eazi Access Eazi Access Eazi Access Eazi Access Eazi Access Manitou SA Manitou SA Manitou SA
Mobile Cranes
Make Maeda Maeda Maeda Tadano Tadano Tadano Tadano
Model MC285 MC305 MC405 GR-150XL GR-350XL GR-550XLL GR-750XL
Operating mass (kg) 1960 3900 5600 13960 27400 38480 43390
Max load @ min extension (t) 2,82 @ 1,4m 2,98 @ 2,5m 3,83 @ 2,7m 13,6 31,8 51 68
Max load @ max extension (t) 550kg @ 8,7m 790kg @ 12,52m 210kg @ 16m 0,35 0,9 0,75 0,8
Max height under hook (m) - - - 24,5 31,8 42,4 43,4
Max height under hook (m) with jib - - - 30 44 56 60,5
Max boom length (m) 8,57 12,48 16,47 23,8 31 42 43
Min boom length (m) 2,53 3,69 4,73 5,5 12,8 12,7 17,7
Max hoist speed (m/min) 9,3 13,5 18 125 133 141 146
Max fly jib (m) - - 20,7 5,5 12,8 15,2 17,7
Make Yanmar Yanmar Yanmar Mitsubishi Cummins Mitsubishi Mitsubishi
4M50-TLE3A QSB6.7 [EPA)
Tier3] 6M60-TLA3B 6M60-TLA3B
Model
2TNV70-NMBA
3TNV76
3TNV88-BPMB
Rated power (kW @ rpm) 7,4 @ 2500 15,2 @ 2500 21,4 @ 2400 129 @ 2700 160 @ 2500 200 @ 2600 200 @ 2600
Length (mm) 3320 4285 4980 7540 11245 13390 13380
Height (mm) 1470 1695 1980 2815 3535 3865 3790
Width (mm) 750 1280 1380 2000 2620 2960 3315
Turning radius (mm) - - - 6500 / 3800 9800 / 5800 10300 / 6000 11900 / 6800
South African Distributor Eazi Access Eazi Access Eazi Access Babcock Babcock Babcock Babcock
