Plant Equipment and Hire Equipment Specs Handbook 2020 | Page 69

Backhoe
Excavators
Tandem
Rollers
Make Ammann Ammann Ammann Ammann Ammann Ammann Ammann
Model ARX 12 ARX 16 ARX 20 ARX 23 ARX 26 ARX 36 ARX 40
Operating weight (kg) 1475 1460 1570 2250 2460 3740 4125
Type Tandem/
Artculated Vibratory Tandem
Roller Vibratory tandem
roller Tandem/
Artculated Tandem/
Artculated Vibratory tandem
roller Vibratory tandem
roller
Drum width (mm 820 900 1000 1000 1200 1300 1300
Nominal amplitude 0,5 0,5 0,5 0,45 0,42 0,36 / 0,55 0,34 / 0,55
Vibration frequency (Hz) 58 / 66 58 / 66 58 / 66 58 / 66 58 / 66 45 / 57 45 / 57
Centrifugal force High/low amp (kN) 23 23 24 41 47 50 52
Make Yanmar Yanmar Yanmar Yanmar Yanmar Yanmar Yanmar
Model 3TNV76 3TNV76 3TNV76 3TNV88 3TNV88 4TNV88 4TNV88
Net power (kW @ rpm) 20,4 @ 2400 20,4 @ 2400 20,4 @ 2400 30,6 @ 2400 30,6 @ 2400 40,8 @ 2400 40,8 @ 2400
Length (mm) 2327 2327 2327 2506 2506 2971 2971
Width (mm) 865 947 1046 1042 1247 1341 1341
Articulation either side (degrees) - - - - - - -
South African distributor ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment
Make Ammann Ammann Ammann Ammann Ammann Atlas Weycor Atlas Weycor
Model ARX 45 ARX 91 AV 70 X AV 110X AV 130 X AW240 AW260
Operating weight (kg) 4650 9200 7715 10400 13100 2700 2900
Type Tandem/
Artculated Tandem/
Artculated Tandem/
Artculated Tandem/
Artculated Tandem/
Artculated Tandem Tandem
Drum width (mm 1380 1700 - 1818 1450 - 1630 1700 - 1630 2100 - 2260 1000 1250
Nominal amplitude 0,34 / 0,55 0,7 / 0,35 0,6 / 0,33 0,7 / 0,35 0,8 / 0,4 0,5 0,5
Vibration frequency (Hz) 45 / 57 42 / 55 48 / 62 45 / 55 42 / 55 53 / 61 53 / 61
Centrifugal force High/low amp (kN) 55 80 / 72 80 / 72 110 / 83 130 / 100 21,5 / 28 25 / 34
Make Yanmar Cummins Cummins Cummins Cummins Deutz Deutz
Model 4TNV88 4B3.3TAA-60-C BTAA 3.3-C80 QSB 3.3-C99 QSB 4.5 C130 D 2011 L2i D 2011 L2i
Net power (kW @ rpm) 40,8 @ 2400 60 @ 2200 60 @ 2200 74 @ 2200 97 @ 2300 22,5 22,5
Length (mm) 2971 4410 4410 4760 4890 2670 2670
Width (mm) 1421 1540 1540 1822 2220 1180 1364
Articulation either side (degrees) - - - - - 30 30
South African distributor ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment Force 8 Force 8
Make Atlas Weycor Bomag Bomag Bomag Bomag Bomag Bomag
Model AW300 BW 65 H BW 75 H BW 90 AD-5 BW 120 AD-5 BW120 AC-5 BW 138 AD-5
Operating weight (kg) 3000 757 1040 1600 2700 2450 4500
Type Tandem TDR pedestrian TDR pedestrian TDR TDR TDR TDR
Drum width (mm 1250 650 750 900 1200 1200 1380
Nominal amplitude 0,5 0,45 0,5 0,5 0,51 / 0,51 0,5 0,5
Vibration frequency (Hz) 52 / 58 55 55 63 / 42 63 / 67 63 / 67 50 / 56
Centrifugal force High/low amp (kN) 29 / 37 22 40 17 / 8 36 / 41 30 / 34 45 / 57
Make Deutz Hatz Yanmar Kubota Kubota Kubota Kubota
Model D 2011 L2i 1D 42 L100EE D 902 D 1703 D 1703 V2203
Net power (kW @ rpm) 22,5 6,2 @ 2800 6,2 @ 3100 15 @ 3000 24,7 @ 2600 24,3 @ 2600 33,6 @ 2400
Length (mm) 2670 2320 3010 2194 2529 2529 2840
Width (mm) 1414 762 865 956 1272 1272 1468
Articulation either side (degrees) 30 - - 33 32 32 32
South African distributor Force 8 Bell Equipment Bell Equipment Bell Equipment Bell Equipment Bell Equipment Bell Equipment
