Mobile fall arresters
ASAP LOCK B71ALU
®
Mobile fall arrester with locking function
Locking function allows the user to immobilize
the device to reduce the length of a fall.
Button for activating locking
function
Catch for locking the wheel
Locking wheel
Connection arm
Connection point for
ASAP'SORBER
• Constant fall protection:
- arrests falls, slides, and uncontrolled descents
- works on vertical or angled rope
- locks on the rope even if grabbed during the fall
• Integrated locking function allows the user to
immobilize the device to reduce the length of a
fall. In case of a strong wind, this function also
prevents the rope from being blown upward.
• Simple to use, and effective:
- moves up or down the rope without any manual
manipulation of the device
- easy to install and remove at any point on the
rope
- connection arm makes the system loss-resistant
when passing intermediate anchors
- is used with an ASAP’SORBER energy
absorbing lanyard to work at a distance from the
rope
• Rope compatibility:
- use according to standard EN 353-2:
AXIS 11 mm rope with sewn termination
- use according to standard EN 12841 type A:
10 to 13 mm ropes, EN 1891 type A
• Weight: 425 g
• Certification(s): CE EN 353-2,
CE EN 12 841 type A, EAC
Connection arm makes the system lossresistant when passing intermediate anchors.
Attachment to the user's harness by means of
an ASAP’SORBER lanyard with energy absorber
(20 or 40 cm).
Find all the possibilities of the ASAP LOCK
mobile fall arrester at
www.petzl.com/ASAP LOCK.
