KL-TECH s.r.o | www.klte.cz HSS/Co end mills CUTTING PARAMETERS INFO N TYPHOO HTA TA-HTA-4 TAWLB2 WLB2 (n and Vf = -20% ÷ -30%) Material Group ISO 513 N TYPHOO PU-HPU N TYPHOO SUH N TYPHOO ALH ae COPYING N TYPHOO I SUH MIN N TYPHOO HL LFTA SUTA /CO HSS-HSS DRILLS G2 MDTA P HF VH/U MEF ALU MEX UH -HSSP HSS/CO LS END MIL CARBIDE BURRS 684 _ P2 P3 M1 P4 K1 M2 P5 K2 M3 ≤ 700 N/mm² 600-800 N/mm² 800-1000 N/mm² 900-1200 N/mm² ap x ae 0.1 D x 0.2 D 0.1 D x 0.2 D 0.1 D x 0.2 D 0.1 D x 0.2 D D D (eff .) (mm) (mm) ap Hardness/Rm Vc (m/min) N TYPHOO HRC C-SD-TA P1 3 4 5 6 8 10 12 14 16 18 20 1.80 2.40 3.00 3.60 4.80 6.00 7.20 8.40 9.60 10.80 12.00 30-50 n (rpm) 25-35 fn Vf (mm/rev) (mm/min) 4250 3180 2550 2120 1590 1270 1060 910 800 710 640 _ n (rpm) Vf (mm/min) 15° x 1.1 x 1.1 0.034 0.051 0.060 0.070 0.080 0.094 0.111 0.128 0.145 0.162 0.179 290 320 300 300 250 240 230 230 230 230 230 n (rpm) 3180 2390 1910 1590 1190 960 800 680 600 530 480 20-30 fn Vf (mm/rev) (mm/min) 0.031 0.046 0.054 0.063 0.072 0.084 0.099 0.115 0.130 0.145 0.161 190 220 200 200 170 160 160 160 160 150 150 n (rpm) 2650 1990 1590 1330 1000 800 660 570 500 440 400 12-18 fn Vf (mm/rev) (mm/min) 0.027 0.041 0.048 0.056 0.064 0.075 0.088 0.102 0.116 0.129 0.143 140 160 150 150 130 120 120 120 120 110 110 n (rpm) 1590 1190 960 800 600 480 400 340 300 270 240 fn Vf (mm/rev) (mm/min) 0.026 0.038 0.045 0.052 0.060 0.070 0.083 0.096 0.108 0.121 0.134 80 90 90 80 70 70 70 70 70 70 60
