KL-TECH s.r.o | www.klte.cz MEX - 30÷55HRC - 45° chamfer CUTTING PARAMETERS INFO MEXCSFR Material Group ISO 513 N TYPHOO HTA TA-HTA-4 N TYPHOO PU-HPU N TYPHOO SUH SLOTTING N TYPHOO ALH N TYPHOO HRC P2 P3 P4 K1 P4 K2 P5 P6 K3 K4 H1 H4 H5 Hardness/Rm < 1000 N/mm² < 35 HRC 35 - 45 HRC 45 - 55 HRC ap x ae 0.5D x D 0.5D x D 0.3D x D 0.1D x D Vc (m/min) 70-90 50-70 40-60 D (mm) n (rpm) 6 8 10 12 14 16 20 4250 3180 2550 2120 1820 1590 1270 fn Vf (mm/rev) (mm/min) 0.043 0.055 0.071 0.085 0.098 0.110 0.140 720 700 720 720 710 700 710 n (rpm) 3180 2390 1910 1590 1360 1190 960 fn Vf (mm/rev) (mm/min) 0.038 0.050 0.064 0.077 0.088 0.099 0.126 490 480 490 490 480 470 480 n (rpm) 2650 1990 1590 1330 1140 1000 800 20-40 fn Vf (mm/rev) (mm/min) 0.034 0.044 0.057 0.068 0.078 0.088 0.112 360 350 360 360 355 350 360 n (rpm) 1590 1190 960 800 680 600 480 fn Vf (mm/rev) (mm/min) 0.030 0.039 0.050 0.060 0.068 0.077 0.098 190 185 190 190 185 185 190 D6-8: Z=3 N TYPHOO I SUH MIN N TYPHOO HL C-SD-TA SIDE MILLING LFTA SUTA /CO HSS-HSS DRILLS G2 MDTA P HF VH/U MEF ALU MEX UH -HSSP HSS/CO LS END MIL CARBIDE BURRS 546 D6-8: Z=3 Hardness/Rm < 1000 N/mm² < 35 HRC 35 - 45 HRC 45 - 55 HRC ap x ae 1.5D x 0.3D 1.5D x 0.3D D x 0.1D D x 0.05D Vc (m/min) 80-100 60-80 50-70 D (mm) n (rpm) 6 8 10 12 14 16 20 4250 3180 2550 2120 1820 1590 1270 fn Vf (mm/rev) (mm/min) 0.047 0.061 0.078 0.094 0.108 0.121 0.154 790 770 800 790 780 770 780 n (rpm) 3180 2390 1910 1590 1360 1190 960 fn Vf (mm/rev) (mm/min) 0.042 0.055 0.070 0.084 0.097 0.109 0.139 540 520 540 540 530 520 530 n (rpm) 2650 1990 1590 1330 1140 1000 800 30-50 fn Vf (mm/rev) (mm/min) 0.037 0.049 0.062 0.075 0.086 0.097 0.123 395 385 395 400 390 385 395 n (rpm) 1590 1190 960 800 680 600 480 fn Vf (mm/rev) (mm/min) 0.033 0.043 0.055 0.065 0.075 0.085 0.108 210 205 210 210 205 205 205
