MEX - 30÷55HRC - Square
MEXCS4
OSAWA
NORM
<55
INFO
cylindrical shank, 4 flutes
TYPHOO
N
TA-HTA-4
HTA
TYPHOO
N
PU-HPU
TYPHOO
N
SUH
P
M
+
+ 1st choice
K
N
S
TYPHOO
N
ALH
H
+
, suitable
+
TYPHOO
N
HRC
SIDE MILLING
TYPHOO
N
SUH MIN
I
D D Tol. d(h6) l L z EDP No. Stock
1 0/-0.030
CR
CR Tol.
4 3
l1
50 4 MEXCS401050 h
1.5 0/-0.030 4 4.5 50 4 MEXCS401550 h
2 0/-0.030 4 6 40 4 MEXCS4020 h
2.5 0/-0.030 4 8 40 4 MEXCS4025 h
3 0/-0.030 6 8 55 4 MEXCS4030 h
3.5 0/-0.030 6 10 55 4 MEXCS4035 h
4 0/-0.030 6 11 55 4 MEXCS4040 h
4.5 0/-0.030 6 11 55 4 MEXCS4045 h
5 0/-0.030 6 13 55 4 MEXCS4050 h
5.5 0/-0.030 6 13 55 4 MEXCS4055 h
6 0/-0.030 6 15 60 4 MEXCS4060 h
6.5 0/-0.030 8 17 65 4 MEXCS4065 h
7 0/-0.030 8 18 65 4 MEXCS4070 h
8 0/-0.030 8 20 70 4 MEXCS4080 h
9 0/-0.030 10 23 70 4 MEXCS4090 h
10 0/-0.030 10 22 75 4 MEXCS4100 h
11 0/-0.030 12 28 75 4 MEXCS4110 h
12 0/-0.030 12 26 80 4 MEXCS4120 h
14 0/-0.030 12 35 90 4 MEXCS4140 h
16 0/-0.030 16 32 100 4 MEXCS4160 h
20 0/-0.030 20 40 100 4 MEXCS4200 h
25 0/-0.030 25 40 100 4 MEXCS4250 h
