KL-TECH s.r.o | www.klte.cz MEX - 30÷55HRC - Square CUTTING PARAMETERS INFO MEXCL2 Material Group ISO 513 N TYPHOO HTA TA-HTA-4 N TYPHOO PU-HPU N TYPHOO ALH N TYPHOO HRC N TYPHOO I SUH MIN N TYPHOO HL C-SD-TA LFTA SUTA /CO HSS-HSS DRILLS G2 MDTA P HF VH/U MEF ALU MEX UH -HSSP HSS/CO LS END MIL CARBIDE BURRS 536 P3 P4 K1 P4 K2 P5 P6 K3 K4 H1 H4 H5 < 1000 N/mm² < 35 HRC 35 - 45 HRC 45 - 55 HRC ap x ae 0.3D x D 0.3D x D 0.2D x D 0.05D x D Vc (m/min) 70-110 50-90 30-70 1 1.5 2 3 4 5 6 8 10 12 < D3: ap = 0.4 mm max SLOTTING Hardness/Rm D (mm) N TYPHOO SUH P2 n (rpm) 28700 19100 14300 9600 7200 5700 4800 3600 2900 2400 fn Vf (mm/rev) (mm/min) 0.005 0.006 0.009 0.012 0.018 0.024 0.029 0.035 0.041 0.050 290 230 260 230 260 270 280 250 240 240 n (rpm) 22300 14900 11100 7400 5600 4500 3700 2800 2200 1900 fn Vf (mm/rev) (mm/min) 0.005 0.005 0.008 0.011 0.016 0.022 0.026 0.032 0.037 0.045 200 160 180 160 180 190 190 180 160 170 n (rpm) 15900 10600 8000 5300 4000 3200 2700 2000 1600 1300 20-40 fn Vf (mm/rev) (mm/min) 0.004 0.005 0.007 0.010 0.014 0.019 0.023 0.028 0.033 0.040 125 100 115 100 115 125 125 110 105 105 n (rpm) 9600 6400 4800 3200 2400 1900 1600 1200 1000 800 fn Vf (mm/rev) (mm/min) 0.004 0.004 0.006 0.008 0.013 0.017 0.020 0.025 0.029 0.035 65 55 60 55 60 65 65 60 55 55
