G2- General purpose- Corner radius

G2CS4R

cylindrical shank, 4 flutes, corner radius
OSAWA NORM
< 45 HRC
INFO
CR
TYPHOON TA-HTA-4HTA
TYPHOON PU-HPU
TYPHOON SUH
P
M
K
N
S
H
�
�
�
�
� 1st choice
� suitable
CR
TYPHOON ALH
TYPHOON HRC
SIDE MILLING
D
D Tol.
CR
CR Tol.
d( h6)
l
l1
L
z
EDP No.
Stock
1
0 /-0.020
0.20
+/-0.010
4
2
50
4
G2CS4R02010
h
1.5
0 /-0.020
0.20
+/-0.010
4
3
50
4
G2CS4R02015
h
1.5
0 /-0.020
0.50
+/-0.010
4
3
50
4
G2CS4R05015
h
2
0 /-0.020
0.20
+/-0.010
4
4
50
4
G2CS4R02020
h
2
0 /-0.020
0.50
+/-0.010
4
4
50
4
G2CS4R05020
h
2.5
0 /-0.020
0.20
+/-0.010
4
5
50
4
G2CS4R02025
h
2.5
0 /-0.020
0.50
+/-0.010
4
5
50
4
G2CS4R05025
h
3
0 /-0.020
0.20
+/-0.010
4
6
50
4
G2CS4R02030
h
3
0 /-0.020
0.50
+/-0.010
4
6
50
4
G2CS4R05030
h
3
0 /-0.020
1.00
+/-0.010
4
6
50
4
G2CS4R10030
h
4
0 /-0.020
0.20
+/-0.010
4
8
50
4
G2CS4R02040
h
4
0 /-0.020
0.50
+/-0.010
4
8
50
4
G2CS4R05040
h
4
0 /-0.020
1.00
+/-0.010
4
8
50
4
G2CS4R10040
h
5
0 /-0.020
0.50
+/-0.010
6
10
50
4
G2CS4R05050
h
5
0 /-0.020
1.00
+/-0.010
6
10
50
4
G2CS4R10050
h
6
0 /-0.020
0.20
+/-0.010
6
12
50
4
G2CS4R02060
h
6
0 /-0.020
0.50
+/-0.010
6
12
50
4
G2CS4R05060
h
6
0 /-0.020
1.00
+/-0.010
6
12
50
4
G2CS4R10060
h
6
0 /-0.020
1.50
+/-0.010
6
12
50
4
G2CS4R15060
h
6
0 /-0.020
2.00
+/-0.010
6
12
50
4
G2CS4R20060
h
8
0 /-0.025
0.50
+/-0.010
8
16
60
4
G2CS4R05080
h
8
0 /-0.025
1.00
+/-0.010
8
16
60
4
G2CS4R10080
h
8
0 /-0.025
1.50
+/-0.010
8
16
60
4
G2CS4R15080
h
8
0 /-0.025
2.00
+/-0.010
8
16
60
4
G2CS4R20080
h
10
0 /-0.025
0.50
+/-0.010
10
20
75
4
G2CS4R05100
h
10
0 /-0.025
1.00
+/-0.010
10
20
75
4
G2CS4R10100
h
10
0 /-0.025
1.50
+/-0.010
10
20
75
4
G2CS4R15100
h
10
0 /-0.025
2.00
+/-0.010
10
20
75
4
G2CS4R20100
h
10
0 /-0.025
2.50
+/-0.010
10
20
75
4
G2CS4R25100
h
10
0 /-0.025
3.00
+/-0.010
10
20
75
4
G2CS4R30100
h
12
0 /-0.025
0.50
+/-0.010
12
24
75
4
G2CS4R05120
h
12
0 /-0.025
1.00
+/-0.010
12
24
75
4
G2CS4R10120
h
12
0 /-0.025
1.50
+/-0.010
12
24
75
4
G2CS4R15120
h
12
0 /-0.025
2.00
+/-0.010
12
24
75
4
G2CS4R20120
h
12
0 /-0.025
2.50
+/-0.010
12
24
75
4
G2CS4R25120
h
12
0 /-0.025
3.00
+/-0.010
12
24
75
4
G2CS4R30120
