KL-TECH s.r.o | www.klte.cz G2 - General purpose - Square CUTTING PARAMETERS INFO GB405 N TYPHOO HTA TA-HTA-4 Material Group ISO 513 N TYPHOO PU-HPU /CO HSS-HSS DRILLS G2 MDTA P HF VH/U MEF ALU MEX UH -HSSP HSS/CO LS END MIL CARBIDE BURRS 336 P3 K2 M2 ap x ae 1.5D x 0.2D 1.5D x 0.2D 1.5D x 0.2D Vc (m/min) 50-70 40-50 20-40 < D3 mm: ae = 0.1D SUTA M1 < 40 HRC N TYPHOO HRC LFTA 700-1000 N/mm² N TYPHOO ALH C-SD-TA P2 K1 < 700 N/mm² SIDE MILLING N TYPHOO HL Hardness/Rm N TYPHOO SUH N TYPHOO I SUH MIN P1 D (mm) n (rpm) 1 2 3 4 5 6 8 10 12 19110 9550 6370 4780 3820 3180 2390 1910 1590 fn Vf (mm/rev) (mm/min) 0.003 0.006 0.010 0.013 0.016 0.020 0.026 0.031 0.036 250 250 250 250 250 260 250 240 230 n (rpm) 14330 7170 4780 3580 2870 2390 1790 1430 1190 fn Vf (mm/rev) (mm/min) 0.003 0.006 0.008 0.011 0.014 0.017 0.022 0.026 0.031 160 160 160 160 160 160 160 150 150 n (rpm) 9550 4780 3180 2390 1910 1590 1190 960 800 N1 N2 N3 N4 1.5D x 0.2D 80-100 fn Vf (mm/rev) (mm/min) 0.002 0.005 0.007 0.010 0.012 0.015 0.019 0.023 0.027 90 90 90 90 90 100 90 90 90 n (rpm) 28660 14330 9550 7170 5730 4780 3580 2870 2390 fn Vf (mm/rev) (mm/min) 0.004 0.008 0.013 0.017 0.021 0.026 0.034 0.040 0.047 480 480 480 480 480 500 480 460 450
