KL-TECH s.r.o | www.klte.cz
G2 - General purpose - Square
G2310-11-12
OSAWA
NORM
<45
HRC
INFO
cylindrical shank, 3 flutes, long
TYPHOO
N
TA-HTA-4
HTA
G2310
TYPHOO
N
PU-HPU
G2311-G2312
P
M
K
N
S
TYPHOO
N
SUH
TYPHOO
N
ALH
H
+
,
+
,
+ 1st choice , suitable
SLOTTING
TYPHOO
N
HRC
SIDE MILLING
TYPHOO
N
SUH MIN
I
D D Tol. d(h6) l L z EDP No. Stock
2 0/-0.030
C
C Tol.
4 9
l1
75 3 G2310020 h
3 0/-0.030 4 15 75 3 G2310030 h
4 0/-0.030 4 20 75 3 G2310040 h
5 0/-0.030 6 25 75 3 G2310050 h
6 0/-0.030 6 25 75 3 G2310060 h
4 0/-0.030 6 25 100 3 G2311040 h
5 0/-0.030 6 30 100 3 G2311050 h
6 0/-0.030 6 30 100 3 G2311060 h
7 0/-0.030 8 35 100 3 G2311070 h
8 0/-0.035 8 35 100 3 G2311080 h
9 0/-0.035 10 40 100 3 G2311090 h
10 0/-0.035 10 40 100 3 G2311100 h
11 0/-0.035 12 45 100 3 G2311110 h
12 0/-0.035 12 45 100 3 G2311120 h
h
8 0/-0.035 8 40 150 3 G2312080 10 0/-0.035 10 50 150 3 G2312100 h
12 0/-0.035 12 50 150 3 G2312120 h
16 0/-0.040 16 70 150 3 G2312160 h
20 0/-0.040 20 80 150 3 G2312200 h
TYPHOO
N
HL
C-SD-TA
LFTA
SUTA
HSS-HSS
/CO
DRILLS
G2
MDTA
HF VH/U
P
MEF
ALU
MEX
UH
HSS/CO
-HSSP
END MIL
LS
CARBIDE
BURRS
h stock standard
f non-standard stock
m stock exhaustion
333
