G2 - General purpose - Square
G2CSH3
OSAWA
NORM
<45
HRC
INFO
cylindrical shank, 3 flutes
TYPHOO
N
TA-HTA-4
HTA
TYPHOO
N
PU-HPU
TYPHOO
N
SUH
P
M
K
N
S
TYPHOO
N
ALH
H
+
,
+
,
+ 1st choice , suitable
SLOTTING
TYPHOO
N
HRC
SIDE MILLING
TYPHOO
N
SUH MIN
I
D D Tol. d(h6) l L z EDP No. Stock
1 0/-0.020
C
C Tol.
4 3
l1
50 3 G2CSH3010 h
1.5 0/-0.020 4 4.5 50 3 G2CSH3015 h
2 0/-0.020 4 6 50 3 G2CSH3020 h
2.5 0/-0.020 4 7 50 3 G2CSH3025 h
3 0/-0.020 4 8 50 3 G2CSH3030 h
3.5 0/-0.020 4 10 50 3 G2CSH3035 h
4 0/-0.020 4 11 50 3 G2CSH3040 h
4.5 0/-0.020 6 13 50 3 G2CSH3045 h
5 0/-0.020 6 13 50 3 G2CSH3050 h
5.5 0/-0.020 6 13 50 3 G2CSH3055 h
6 0/-0.020 6 15 50 3 G2CSH3060 h
6.5 0/-0.025 8 17 60 3 G2CSH3065 h
7 0/-0.025 8 17 60 3 G2CSH3070 h
7.5 0/-0.025 8 17 60 3 G2CSH3075 h
8 0/-0.025 8 20 60 3 G2CSH3080 h
8.5 0/-0.025 10 23 75 3 G2CSH3085 h
9 0/-0.025 10 23 75 3 G2CSH3090 h
10 0/-0.025 10 30 75 3 G2CSH3100 h
11 0/-0.025 12 28 75 3 G2CSH3110 h
12 0/-0.025 12 30 75 3 G2CSH3120 h
14 0/-0.030 14 26 83 3 G2CSH3140 h
16 0/-0.030 16 32 92 3 G2CSH3160 h
18 0/-0.030 20 40 100 3 G2CSH3180 h
20 0/-0.030 20 40 100 3 G2CSH3200 h
TYPHOO
N
HL
C-SD-TA
LFTA
SUTA
HSS-HSS
/CO
DRILLS
G2
MDTA
HF VH/U
P
MEF
ALU
MEX
UH
HSS/CO
-HSSP
END MIL
LS
CARBIDE
BURRS
h stock standard
f non-standard stock
m stock exhaustion
