TYPHOON - high performance solid carbide drills
CUTTING PARAMETERS
INFO
3520SUH MINI
Material Group
ISO 513
P1

P2
P3

P4
P5 P6
TYPHOO
N
TA-HTA-4
HTA
Hardness/Rm 500-700 N/mm² 600-1000 N/mm² 900-1200 N/mm² 1200-1400 N/mm²
Vc (m/min) 45-65* 40-50* 30-40* 20-30*
D
(mm)
n
(rpm)
fn
Vf
(mm/rev) (mm/min)
n
(rpm)
fn
Vf
(mm/rev) (mm/min)
n
(rpm)
fn
Vf
(mm/rev) (mm/min)
n
(rpm)
fn
Vf
(mm/rev) (mm/min)
1.0
17520 0.0063
110
14330 0.0057
80
11150 0.0050
56
7960
0.0044
1.1
15920 0.0070
110
13030 0.0063
80
10130 0.0056
57
7240
0.0049
1.2
14600 0.0077
110
11940 0.0069
80
9290
0.0062
57
6630
0.0054
1.3
13470 0.0084
110
11020 0.0076
80
8570
0.0067
58
6120
0.0059
1.4
12510 0.0091
110
10240 0.0082
80
7960
0.0073
58
5690
0.0064
1.5
11680 0.0105
120
9550
0.0095
90
7430
0.0084
60
5310
0.0074
1.6
10950 0.0119
130
8960
0.0107
100
6970
0.0095
70
4980
0.0083
Ø RUN OUT
1.7
10300 0.0133
140
8430
0.0120
100
6560
0
