KL-TECH s.r.o | www.klte.cz
TYPHOON SUH MINI
HIGH PERFORMANCE - MINIATURE SHORT AND LONG
INFO
N
TYPHOO
HTA
TA-HTA-4
N
TYPHOO
PU-HPU
N
TYPHOO
SUH
N
TYPHOO
ALH
N
TYPHOO
HRC
N
TYPHOO
I
SUH MIN
- Miniature drills are manufactured with
unified 3 mm shank
- Oil holes for internal coolant feed
- Self-centering geometry: highly accurate
holes
- Straight and reinforced edge: high stability
and chipping resistance
- Edge geometry: special design for edge
and corners protection
- Chip pocket: highly polished to prevent
welding and to improve the chip ejection
- Substrate and coating: specifically selected
for high wear resistance, long and reliable
life
- Available from Ø1 mm to Ø3 mm
- Different cutting length types from short
(5xD) to extra-long (30xD) - Mini forets fabriqués avec une tige unifiée
ayant un diamètre de 3 mm
- Trous de lubrification
- Affûtage autocentré pour l’exécution de
trous précis et peu d’efforts de coupe
- Profil de l’arête droit et renforcé : il génère
des copeaux courts et garantit une grande
fiabilité
- Géométrie de l’arête avec affûtage
spécifique pour protéger l’arête et les
angles
- Finition des goujoures : polie pour
réduire le problème du collage et faciliter
l’évacuation des copeaux
- Substrat et revêtement : spécifiques pour
garantir durée et fiabilité
- Disponibles du Ø1 mm au Ø3 mm
- Différents types de longueur, de la plus
courte (5xD) aux extra-longues (30xD)
- Mini-punte costruite con gambo unificato
Ø3 mm
- Fori di refrigerazione
- Affilatura autocentrante per l’esecuzione di
fori precisi e bassi sforzi di taglio
- Profilo del tagliente diritto e rinforzato:
genera trucioli corti e garantisce grande
affidabilità
- Geometria del tagliente con affilatura
specifica a protezione del tagliente e degli
spigoli
- Finitura gole: lappate per ridurre il
problema dell’incollaggio e facilitare
l’evacuazione dei trucioli
- Substrato e rivestimento: specifici per
garantire durata e affidabilità
- Disponibili da Ø1 mm a Ø3 mm
- Differenti tipi di lunghezza, dalle corte
(5XD) alle extra-lunghe (30XD) - Mini-brocas fabricadas con mango
unificado con diámetro de 3 mm
- Agujeros de refrigeración
- Afilado autocentrante para la realización
de agujeros precisos y bajos esfuerzos de
corte
- Perfil del filo recto y reforzado: genera
virutas cortas y garantiza una gran fiabilidad
- Geometría del filo con afilado específico
para proteger el filo y los ángulos
- Acabado ranuras: lapeadas para reducir
el problema del encolado y facilitar la
evacuación de las virutas
- Sustrato y revestimiento: específicos para
garantizar duración y fiabilidad
- Disponibles de Ø1 mm a Ø3mm
- Diferentes tipos de longitud, desde las
cortas (5XD) hasta las extra-largas (30XD)
- Kleinstbohrer mit genormtem Schaft und
einem Durchmesser von 3 mm
- Kühlöffnungen
- Selbstzentrierender Schliff für präzise
Bohrungen und geringen Schneiddruck
- Gerades und verstärktes Schneidkantenprofil:
z
