Modular Support Systems Technical Guide, Edition 2
3.0 Modular Support System
3.2.11 MT Media Fixation
MP-US OC
Description
Pipe strap designed for use with open channel profiles, closed girders and bracket arms.
Material Specifications
Standard EN 10346:2016
Grade DX51D-ZM300
Corrosion Protection
Description
U-Bolt MP-UB 1-1 / 2” to 24” OC
Environmental Conditions
Outdoor, low to moderate pollution( C3 / C4- low)
Ordering Information
Description
Pipe Strap MP-US 18 3 / 8” OC Pipe Strap MP-US 22 1 / 2” OC Pipe Strap MP-US 28 3 / 4” OC Pipe Strap MP-US 34 1” OC Pipe Strap MP-US 43 1-1 / 4” OC Pipe Strap MP-US 49 1-1 / 2” OC Pipe Strap MP-US 61 2” OC Pipe Strap MP-US 77 2-1 / 2” OC Pipe Strap MP-US 90 3” OC Pipe Strap MP-US 102 3-1 / 2” OC Pipe Strap MP-US 115 4” OC Pipe Strap MP-US 139 5” OC Pipe Strap MP-US 169 6” OC Pipe Strap MP-US 221 8” OC Pipe Strap MP-US 275 10” OC Pipe Strap MP-US 326 12” OC
Weight Per Piece, lbs( kg)
0.157( 0.071) 0.170( 0.077) 0.187( 0.085) 0.212( 0.096) 0.240( 0.109) 0.258( 0.117) 0.298( 0.135) 0.353( 0.160) 0.395( 0.179) 0.741( 0.336) 0.809( 0.367) 0.948( 0.430) 1.118( 0.507) 1.411( 0.640) 2.178( 0.988) 2.511( 1.139)
Quantity Piece( s)
Item No.
Diameter“ d”, in
Height“ H” in
Width“ B” in mm( in)
Distance Btwn Holes“ A” in
Cross- Section Width“ b” in
Cross- Section Thickness“ s”, in
40 2288314 0.8 0.6 5.06 3.17 1.18 0.1
40 2288315 0.9 0.8 5.22 3.33 1.18 0.1 40 2288316 1.2 1 5.44 3.56 1.18 0.1 20 2288317 1.4 1.3 5.71 3.82 1.18 0.1 20 2288318 1.8 1.6 6.06 4.17 1.18 0.1 20 2288319 2 1.8 6.3 4.41 1.18 0.1 20 2288370 2.5 2.3 6.78 4.89 1.18 0.1 10 2288371 3.1 2.9 7.4 5.51 1.18 0.1 10 2288372 3.6 3.4 7.9 6.01 1.18 0.1 10 2288373 4.1 3.9 9.07 6.91 1.57 0.12 10 2288374 4.6 4.4 9.6 7.44 1.57 0.12 10 2288950 5.6 5.4 10.61 8.44 1.57 0.12 2 2288376 6.8 6.5 12.12 9.96 1.57 0.12 2 2288377 8.8 8.5 14.55 12.38 1.57 0.12 2 2288378 10.9 10.6 17.46 14.94 1.97 0.12 2 2288379 12.9 12.6 19.46 16.94 1.97 0.12
182 Modular Support Systems Technical Guide Edition 2 | Installation Systems Hilti, Inc. 1-800-879-8000 | en español 1-800-879-5000 | www. hilti. com | Hilti( Canada) Corporation | 1-800-363-4458 | www. hilti. ca
