t Form AD/B standard for all holders HI-POWER MILLING CHUCK
microns t Data chip hole as standard for all
HSK & SK taper holders t Very high clamping force leads to
increased productivity and tool life
t Fine bore cartridges designed for
standard ISO Inserts t Bore tolerance H4 as standard for all t Roller bearing design provides high
friction resistance
areas, no need of eye contact
t Least count
diametrically
of
2
t Boring range : Ø8mm - Ø390mm
Mod-Flex system (Modular + Flexible
system): t High run out accuracy within 5
micron @ 3D. Less wear on cutting
edge leads to significant increase in
tool life
t The tool has high rigidity because of
OD & face contact t Excellent finish on machined surface
due to less vibration
t Using modular systems means
flexible tool determination and cost
reducing investment t Protected
coating
with
anti-corrosive
Special boring solutions:
Bilz special boring bar solution with ISO
cartridge, ISO insert and Microbore unit
have been field proven successfully in
producing multiple bores and chamfers
to customer specific tolerance, which
gives improved productivity to the
customer
CNC TOOL HOLDERS
t Perfect seal mechanism of clamping
nut, prevents dust and coolant entry,
extending the life of the holder
side lock holders
t Comprehensive range of 1100 line
items SLIM HI-POWER MILLING CHUCK
(SLIM HPMC)
t BT (JIS B 6339 / MAS 403), SK (DIN
69871), HSK (DIN 69893) tapers t Clamping torque is twice that
of collet chucks with ISO15488
(DIN6499)
t All tool holders have taper angle
accuracy as per AT3 class
t TIR of front end w.r.t taper controlled
t All holders are dynamically balanced
and also can be fine balanced
50 | may-june 2019
t Collet: ER Collet, Tap Collet, Straight
collet, Super collet & Collet Set
t Slim design helps to reach depth
without fouling t Clamping nut, Spanner, Sealing disc,
Pull stud, Friction wrench
t Clamping nut without slots makes its
usage at higher rpm effortless t Cylindrical shank, Coolant tube for
HSK chuck
t Run-out consistency
microns at 4D t Reduction sleeves for hydraulic
chuck with sleeve remover
t Powerful and Rigid
within 3 microns
ACCESSORIES FOR CNC TOOL HOLDERS
within
5
t Threaded arbor - extension &
reductions
t Spare parts required for holders
like locking screw, adjusting screw,
socket head screw, stopper screw,
drive keys, threaded stud, etc
www.bilzindia.com
