Company’s computer control system
enables a machine tool operator to
create two-dimensional or three-
dimensional (3D) machining programs
from an engineering drawing or
computer-aided design geometry file.
In addition, WinMax has a Windows-
based operating system. Its offering
of machining centers, equipped with
either a twin touch-screen console
or a single touch-screen console,
consists of the product lines, such as
VM(General Purpose Vertical Milling)
Product
Line,
VMX(Performance
Vertical Milling) Product Line, BX(Bridge
Type Vertical Milling) Product line,
Five-Axis Product Line, HS(High Speed)
Product Line, HMX(Horizontal Milling)
Product Line, HBMX(Horizontal Boring-
mill) Product Line, TM/TMM(General
Turning & Turnmill ) Product Line,
TMX(Performance Turning & Turn-
mill with Y-axis) Product Line and
DCX(Double Column Vertical Milling)
Product Line which enables users
to improve shop floor flexibility and
productivity.
Double-Column Machining Center, BX
Series
BX40i is designed for high precision
29 | may-june 2019
application for Die & mould, Tool Room
and Aerospace segments. The machine
is of Bridge structure with bigger Y axis
stroke. X / Y / Z stroke are 1020 / 700
/ 500. A bigger Y axis stroke is always
an advantage in machining of multi
cavity moulds and square moulds. The
machine is with integral spindle with
chiller unit. The 35 KW spindle with
18000 rpm speed and 119 Nm torque
gives customer a free hand to machine
a job from roughing to finishing in one
setup.
The chip conveyor, linear scale on all 3
axis, spindle chiller, panel cooler, CTS
are standard on this machine to ensure
best performance.
VMX42 SRTi- Swivel head/ rotary
machine designed for high mix
manufacturing.
Hurco is one of the few machine tool
companies in the world who are having
all types of 5 axis machines with proven
track record. Hurco 5 axis technology
is the most popular and appreciated
machine model is VMX42SRTi. This is
a most versatile machine as compare
to other five axis machine available in
market. It comes with a Tilting spindle
Global
MDA
Journal
and submerged rotary table of Dia. 600
mm and total bed size 1270 mm x 610
mm. Both the tilting spindle and rotary
table is with high performance Torque
motor with chiller unit. The 36 KW
integral spindle with 12000 rpm speed
and 118 Nm torque can ensure high
performance machining of all types of
material. It can serve various industries
like die & mould, aerospace and general
engineering. It can be used as 3 axis, 4
axis and 5 axis simultaneous depending
on application. It has a work envelope
of 1270 mm x 610 mm x 610 mm which
allows customer to machine bigger and
complex jobs which are not possible on
other five axis machines due to a small
work envelope and weight carrying
capacity. We request you to follow the
link
http://www.HurcoCanHelp.com
which will give more clarity on the
advantage of using Hurco controller.
The machine is equipped with worlds’
most preferred and user friendly
controller Max 5 powered with
WINMAX software. Max-5 controller
comes with the latest technology
available in the market and having
lots of advance features like superior
motion & jerk control with the help
of patented software Ultimotion, 4GB
Program Memory,128GB machine
Memory, latest high speed Processor
of 0.44mS, 3D simulation graphics,
Interrupt function, variable Look-ahead
function of 10,000 blocks. The tool path
generation by Conversational & NC
Mode or both – enables the end user
to reduce the end to end processing
time. It has capability of ‘rationalizing’
the tool path – enables high speed
machining with exceptional control
of acceleration & deceleration of the
machine slides resulting in reduced
machining time, increases surface finish
& accuracy. The controller is compatible
for IOT and has many optional software
to cover wide range of applications.
