BOLLYTERM® HP
POLYWARM® COATED CALORIFIERS WITH INTEGRATED HEAT PUMP
APPLICATION
Production and storage of sanitary hot water
MATERIAL
Material and finishings, suitable drinkable water according to D. M. n.
174 dated 06.04.04,:
- Mild steel Polywarm® coated (certification ACS - SSICA - DVGW - W270
- UBA - WRAS)
HEAT EXCHANGER
The thermal exchange is ensured by:
- integrated heat pump
- “plug&play” electrical immersion resistance - 1500 Watt
INSULATION
Ecological hard polyurethane foam, thickness 45 mm with high thermal
insulation and thermal conductivity 0,023 W/mK.
PVC external lining complete with ABS top and flange cover.
HEAT PUMP
Integrated heat pump - C.O.P. 2,95 According to en 16147 insulated
compressor with ecological coolant r134a
CATHODE PROTECTION
Magnesium anode with Anoden Tester
DRAIN
External confluence through drain connection.
GASKET- FLANGE PLATE
Silicone gaskets suitable for alimentary use for max temperature up to
200°C. Flange plate.
WARRANTY
- 5 years (Polywarm®)
See general sales conditions and warranty for electrical parts
ACCESSORIES AND SPARE PARTS : See page 216
BOLLYTERM® HP
Model
200
300
Model
Net volume heated
from heat pump
200
300
[liters]
176
264
Room
temperature
min/max
[°C]
-5/+44
Heat Pump
thermal output
C.O.P.
[W]
D.H.W. Storage: POLYWARM® coated
Art. Nr.
3180162330102
3180162330103
Average electrical
power absorbed
by the Heat Pump
[W]
Ignition time
Price €
2.553,00
2.604,00
Electrical
integration
power
[W]
[min]
236’
2020
4,16
486
1500
353’
Data obtained under the following conditions (T air 20 °C - T water from 15 °C to 55 °C)
INTEGRATED HEAT PUMP
Bollyterm is 2,95(*).
The C.O.P on the Bollyterm® HP Cordivari is 2,95(*) and allows to heat the water in
an ecological, economical and easy way.
Besides, the Bollytherm HP is already equipped as standard with a 1500 watt
electrical immersion heater to help the thermodynamic working in some situation.
• C.O.P. 2,95 according to EN 16147 (T air 20 °C T water 48,5 °C)
• Insulated compressor with ecological coolant R134A
• Heat pump condensator coil external to the tank avoiding any contact Gas-domestic
hot water
• Radial fan
COMPRESSOR
• Electronic control display
Power
supply
Max water
temperature
[V / Ph / Hz]
[°C]
220-240 / 1 / 50
60
Coolant
Pressure
Acoustic
level
[tipo]
[g]
850
46
C.O.P.
Inlet and
outlet air
capacity
[m3/h]
2,95 (*)
700
db (A)
R134a
Coolant
[m / Pa]
Minimum
pipes
diameter
[mm]
8 / 60
180
Max pipes
lenght
(*) according to EN 16147 (T air 20 °C - T water 48,5 °C)
Accessories on request
Thermometer
Art. Nr.
5032240000107
5 units box
Titanium electronic anode
€
80,00
Art. Nr.
€
Model
5200000000008 220,00
96
200,300
Suitable for
Polywarm®
coated models
Heat transferred
from cold fluid
EVAPORATOR
HEAT PUMP TECHNICAL DATA
CONDE NSATOR
Expansion
valve
HEAT PUMP
Heat transferred
to hot fluid
The Bollyterm HP produces DHW thanks to the heat energy naturally present in the
air, allowing considerable energy savings.
The functioning of heat pump is based on the exploitation of a particular ecological
gas (R134) that, through its compression and expansion, ensures high performance
and cost efficiency.
The energy (heat) is transferred from the air to the water through a condenser coil
wrapped outside the tank, avoiding any possible contact between the fluid and the
sanitary water, ensuring therefore maximum hygiene and safety
The output is indicated by the coefficient of performance C.O.P. indicating the relation
between used and obtained energy. Besides, the Bollyterm® HP is already equipped
with additional electrical immersion of 1500 watt back up system. The C.O.P. on
