PLATE HEAT EXCHANGERS
PROMPT DELIVERY

EXCHANGERS PHC 12046

(1-5 days to dispatch-delivery time excluded)

460
223

3

2

4

935

1197

1

N°
of
PLATES

334

L
S

CONNECTIONS
DN 100 PN16
1
Primary Inlet
2 Primary Outlet
3 Secondary Outlet
4 Secondary Inlet

Art. Nr.

Price [€]

S Fixing
quote

L

Primary Vol.
= Secondary Vol.

Output (*)

Primary Secondary
Primary Secondary
Pressure Pressure
Flow rate Flow rate
loss
loss

[mm]
[mm]
[lt ]
[Kcal/h] [KW]
[m3/h]
[m3/h]
[m.c.a.]
[m.c.a.]
13
3175056654013 3.950,00
40
5,07
64488
75
13,23
13,22
2,77
2,83
15
3175056654015 4.145,00
47
5,92
77386
90
15,89
15,86
2,91
2,97
17
3175056654017 4.340,00
53
6,76
85985
100
17,66
17,62
2,77
2,83
19
3175056654019 4.535,00
59
7,61
94583
110
19,42
19,39
2,66
2,71
21
3175056654021 4.730,00
65
8,45
103181
120
22,95
22,91
2,97
3,03
23
3175056654023 4.925,00
71
9,30
120378
140
24,72
24,67
2,86
2,92
25
3175056654025 5.120,00
78
10,14
137575
160
28,25
28,20
3,30
3,00
27
3175056654027 5.315,00
84
10,99
146174
170
30,02
29,96
3,27
3,33
29
3175056654029 5.595,00
90
11,83
154772
180
31,78
31,72
2,91
2,97
31
3175056654031 5.790,00
96
12,68
171969
200
35,31
35,25
3,22
3,27
33
3175056654033 5.985,00
102
13,52
189166
220
38,85
38,77
3,28
3,35
35
3175056654035 6.180,00
109
14,37
206363
240
42,38
42,30
3,60
3,30
37
3175056654037 6.375,00
115
550
15,21
214961
250
44,14
44,06
3,34
3,41
39
3175056654039 6.570,00
121
16,06
223560
260
45,91
45,82
3,25
3,32
41
3175056654041 6.765,00
127
16,90
240757
280
49,44
49,34
3,39
3,46
43
3175056654043 6.960,00
133
17,75
249355
290
51,21
51,11
3,31
3,38
45
3175056654045 7.155,00
140
18,59
257954
300
52,97
52,87
3,40
3,00
47
3175056654047 7.450,00
146
19,44
275150
320
56,50
56,39
3,35
3,42
49
3175056654049 7.645,00
152
20,28
283749
330
58,27
58,16
3,28
3,35
51
3175056654051 7.840,00
158
21,13
300946
350
61,80
61,68
3,39
3,46
53
3175056654053 8.035,00
164
21,97
309544
360
63,57
63,44
3,32
3,39
55
3175056654055 8.230,00
171
22,82
326741
380
67,10
66,97
3,50
3,30
57
3175056654057 8.425,00
177
23,66
335340
390
68,86
68,73
3,36
3,43
59
3175056654059 8.620,00
183
24,51
343938
400
70,63
70,49
3,42
3,48
61
3175056654061 8.815,00
189
25,35
361135
420
74,16
74,02
3,70
3,50
63
3175056654063 9.010,00
195
26,20
369733
430
75,93
75,78
3,33
3,40
65
3175056654065 9.205,00
202
27,04
386930
450
79,22
79,30
3,42
3,49
67
3175056654067 9.550,00
208
27,89
395529
460
81,22
51,07
3,36
3,43
69
3175056654069 9.745,00
214
28,73
412726
480
84,75
84,59
3,44
3,51
71
3175056654071 9.940,00
220
29,58
421324
490
86,52
86,35
3,50
3,40
73
3175056654073 10.135,00
226
30,42
438521
510
90,05
89,88
3,46
3,53
75
3175056654075 10.330,00
233
31,27
447120
520
91,82
91,64
3,41
3,48
77
3175056654077 10.525,00
239
32,11
464316
540
95,35
95,16
3,48
3,55
79
3175056654079 10.720,00
245
32,96
472915
550
97,11
96,93
3,43
3,51
81
3175056654081 10.915,00
251
33,80
481513
560
98,88
98,69
3,39
3,46
83
3175056654083 11.110,00
257
34,65
490112
570
100,64
100,45
3,35
3,42
85
3175056654085 11.305,00
264
35,49
498710
580
102,41
102,21
3,45
3,53
87
3175056654087 11.500,00
270
36,34
515907
600
105,94
105,94
3,37
3,44
89
3175056654089 11.695,00
276
37,18
533104
620
109,47
109,26
3,43
3,50
710
91
3175056654091 11.890,00
282
38,03
550301
640
113,00
112,78
3,49
3,56
93
3175056654093 12.085,00
288
38,87
567498
660
116,53
116,31
3,54
3,62
95
3175056654095 12.280,00
295
39,72
584695
680
120,06
119,83
3,60
3,67
97
3175056654097 12.475,00
301
40,56
593293
690
121,83
121,59
3,55
3,55
99
3175056654099 12.670,00
307
41,41
601892
700
123,60
123,36
3,52
3,59
101
3175056654101 12.865,00
313
42,25
610490
710
125,36
125,12
3,48
3,55
103
3175056654103 13.060,00
319
43,10
619089
720
127,13
126,88
3,44
3,51
105
3175056654105 13.255,00
326
43,94
627687
730
128,89
128,89
3,41
3,48
107
3175056654107 13.450,00
332
44,79
636285
740
130,66
130,40
3,37
3,44
109
3175056654109 13.645,00
338
45,63
644884
750
132,42
132,17
3,34
3,41
111
3175056654111 13.840,00
344
46,48
653482
760
134,19
134,93
3,31
3,38
113
3175056654113 14.035,00
350
47,32
662081
770
135,96
135,69
3,28
3,35
115
3175056654115 14.230,00
357
48,17
670679
780
137,72
137,45
3,22
3,28
Output is referred to water/water heat exchanging with primary inlet temperature 80 °C and production of DHW from 70 °C input to 75 °C output. For
other working condition (different fluide and/or temperatures) dimensioning from our technical dept. is required.
