PLATE HEAT EXCHANGERS
PROMPT DELIVERY

EXCHANGERS PHC 7431

(1-5 days to dispatch-delivery time excluded)

310

N°
of
PLATES

124

3

745

603

1

4

2

210

L
S

100

CONNECTIONS
2”1/2
1
Primary Inlet
2 Primary Outlet
3 Secondary Outlet
4 Secondary Inlet

Art. Nr.

Price [€]

S Fixing
quote

L

Primary Vol.
= Secondary Vol.

Output (*)

Primary Secondary
Primary Secondary
Pressure Pressure
Flow rate Flow rate
loss
loss

[mm]
[mm]
[lt ]
[Kcal/h]
[KW]
[m3/h]
[m3/h]
[m.c.a.]
[m.c.a.]
13
3175056653013 1.900,00
46
1,68
288048
335
14,75
8,29
3,88
1,73
15
3175056653015 2.035,00
53
1,96
348237
405
17,83
10,02
4,14
1,84
17
3175056653017 2.170,00
60
2,24
386930
450
19,81
11,14
3,94
1,75
19
3175056653019 2.305,00
66
2,52
429923
500
22,01
12,37
3,85
1,71
405
21
3175056653021 2.440,00
73
2,80
474635
552
24,30
13,66
3,81
1,69
23
3175056653023 2.575,00
80
3,08
550301
640
28,17
15,84
4,18
1,86
25
3175056653025 2.710,00
87
3,36
646604
752
33,10
18,61
4,77
2,12
27
3175056653027 2.845,00
94
3,64
706793
822
36,18
20,34
4,85
2,16
29
3175056653029 2.900,00
101
3,92
766982
892
39,26
22,07
4,92
2,19
31
3175056653031 3.035,00
108
4,20
827171
962
42,34
23,81
4,98
2,21
33
3175056653033 3.170,00
114
4,48
887360
1032
45,42
25,54
5,03
2,24
35
3175056653035 3.305,00
121
4,76
947549
1102
48,50
27,27
5,07
2,26
37
3175056653037 3.440,00
128
505
5,04
1007739 1172
51,59
29,00
5,11
2,27
39
3175056653039 3.575,00
135
5,32
1067928 1242
54,67
30,73
5,15
2,29
41
3175056653041 3.710,00
142
5,60
1128117
1312
57,75
32,47
5,18
2,30
43
3175056653043 3.845,00
149
5,88
1187446 1381
60,78
34,17
5,20
2,31
45
3175056653045 3.980,00
155
6,16
1246776 1450
63,82
35,88
5,22
2,32
47
3175056653047 4.050,00
162
6,44
1306965 1520
66,90
37,61
5,25
2,33
49
3175056653049 4.185,00
169
6,72
1367154 1590
69,98
39,35
5,27
2,34
51
3175056653051 4.320,00
176
7,00
1427343 1660
73,06
41,08
5,29
2,35
53
3175056653053 4.455,00
183
7,28
1487532 1730
76,15
42,81
5,31
2,36
55
3175056653055 4.590,00
190
7,56
1547721 1800
79,23
44,54
5,33
2,37
605
57
3175056653057 4.725,00
196
7,84
1569218 1825
79,14
45,16
4,99
2,28
59
3175056653059 4.860,00
203
8,12
1590714 1850
79,43
45,78
4,72
2,19
61
3175056653061 4.995,00
210
8,40
1612210 1875
79,34
46,40
4,44
2,11
63
3175056653063 5.130,00
217
8,68
1633706 1900
79,25
47,02
4,18
2,04
65
3175056653065 5.265,00
224
8,96
1650903 1920
76,80
47,51
3,74
1,96
67
3175056653067 5.300,00
231
9,24
1668100 1940
77,60
48,01
3,61
1,89
69
3175056653069 5.435,00
237
9,52
1685297 1960
76,65
48,50
3,35
1,83
71
3175056653071 5.570,00
244
9,80
1702494 1980
75,77
49,00
3,12
1,77
251
10,08
1719690 2000
76,50
48,49
3,02
1,71
73
3175056653073 5.705,00
75
3175056653075 5.840,00
258
10,36
1736887 2020
75,62
49,99
2,82
1,66
77
3175056653077 5.975,00
265
10,64
1754084 2040
74,77
50,48
2,64
1,61
79
3175056653079 6.110,00
272
10,92
1771281 2060
75,50
50,98
2,56
1,56
81
3175056653081 6.245,00
279
11,20
1788478 2080
74,37
51,47
2,39
1,52
83
3175056653083 6.380,00
285
11,48
1805675 2100
73,87
51,97
2,26
1,48
85
3175056653085 6.515,00
292
11,76
1814273 2110
73,63
52,21
2,15
1,43
87
3175056653087 6.650,00
299
12,04
1831470 2130
73,45
52,71
2,05
1,39
89
3175056653089 6.785,00
306
12,32
1848667 2150
74,15
53,20
2,00
1,36
91
3175056653091 6.920,00
313
12,60
1865864 2170
73,39
53,70
1,89
1,33
855
93
3175056653093 7.055,00
320
12,88
1900258 2210
74,16
54,69
1,86
1,32
95
3175056653095 7.190,00
326
13,16
1926053 2240
75,17
55,43
1,83
1,30
97
3175056653097 7.325,00
333
13,44
1951849 2270
75,31
56,17
1,77
1,28
99
3175056653099 7.460,00
340
13,72
1977644 2300
76,31
56,91
1,75
1,27
101
3175056653101 7.595,00
347
14,00
2003439 2330
77,30
57,66
1,72
1,25
103
3175056653103 7.730,00
354
14,28
2029235 2360
77,42
58,40
1,67
1,23
105
3175056653105 7.865,00
361
14,56
2055030 2390
78,40
59,14
1,65
1,22
107
3175056653107 8.000,00
367
14,84
2080825 2420
79,79
59,88
1,61
1,20
109
3175056653109 8.135,00
374
15,12
2106621 2450
79,77
60,63
1,59
1,19
111
3175056653111 8.270,00
381
15,40
2132416 2480
79,56
61,37
1,53
1,18
113
3175056653113 8.405,00
388
15,68
2149613 2500
79,91
61,86
1,50
1,16
115
3175056653115 8.540,00
395
15,96
2162511 2515
79,80
62,24
1,45
1,13
Output is referred to water/water heat exchanging with primary inlet temperature 80 °C and production of DHW from 10 °C input to 45 °C output. For
other working condition (different fluide and/or temperatures) dimensioning from our technical dept. is required.
