DHW
STAINLESS STEEL PLATE
HEAT EXCHANGER (MACS®) HARDNESS
Pmax
Tmax
F max
6 bar
99 °C
30 °f
De
Df
(19)
H13 (16)
(17) (18)
H11 (14)
20
H10 (12) (13)
H9(11)
21
Heating return/To Generator 1”1/2 Gas F
Lower heat exchanger outlet 1” Gas F
Connection for instrumentation 1/2” Gas F
Lower heat exchanger inlet 1” Gas F
Electrical immersion resistance 1”1/2 Gas F
Connection for instrumentation 1/2” Gas F
Heating delivery/From Generator 1”1/2 Gas F
Connection for instrumentation 1/2” Gas F
Heating delivery 1”1/2 Gas F
Domestic cold water circuit inlet 1” Gas M
(3/4” for models from 500 to 1500)
Domestic hot water circuit outlet 1” Gas M
(3/4” for models from 500 to 1500)
MULTIFUEL ENERGY
1-2-6-7
3
4-5
8
9
11
12-13-16-18
14-17
19
MODULE
HEAT
EXCHANGER
Pmax Tmax Pmax Tmax
3 bar 99 °C 12 bar 110 °C
STORAGE
MACS®
HEATING WATER BUFFER TANK WITH 1 FIXED HEAT EXCHANGER AND
MACS® MODULE FOR IMMEDIATE D.H.W. PRODUCTION
H
H7 (9)
H6 (8)
H5 (6) (7)
H4 (5)
(19)
H3 (4)
H2 (3)
H1 (1)(2)
(2) (7) (9)
(13) (18)
(3)(4)(5)
50°
(8)(11)
(14)(17)
(1) (6) (12)
(16)
0
50°
(20) (21)
Df
Model
P.E.D. product planned and produced in conformity to the article 3.3 of directive 92/23/CE
P.E.D. product planned and produced in conformity to the article 3.3 of directive 92/23/CE
PUFFERMAS® 1
De
H
A
H1
H2
H3
H4
H5
H6
H7
H9
H10
H11
H13
360
360
378
384
432
533
582
584
656
736
629
695
690
787
845
744
855
762
953
1006
870
970
918
1145
1236
1025
1200
1115
1388
1396
1011
1144
1115
1309
1377
1130
1485
1442
1588
1783
1343
1593
1541
1831
1909
[mm]
650
650
790
790
950
500
600
800
1000
1500
850
850
990
990
1150
1619
1870
1840
2130
2250
1666
1915
1895
2180
2315
247
247
265
265
313
260
260
278
284
336
MACS® MODULE FOR IMMEDIATE D.H.W. PRODUCTION
B
M
A
N
I
L
E
G
D
C
H
K
O
I
F
J
MACS® module is an external unit that immediately produces
hot domestic water, using the heat energy stored in the Buffer
thanks to the stainless steel plate exchanger, granting safety
and comfort with the possibility to regulate outlet temperature.
MACS® module is equipped with a thermostatic mixer in the
primary circuit inlet avoiding the plate exchanger to overheat
reducing risk of formation of calcium deposist.
A
B
C
D
E
F
G
H
I
J
K
L
Domestic Hot Water exit
Domestic Water entry
Stainless Steel Plate Exchanger
Control for thermostatic head
Entry heating water from the buffer
Heating water back to the buffer
“Energy Saving” Circulation Pump
Thermostatic Valve
Valves In/Out for DHW
Flow Sensor
Heating Circuit Bypass
Drain
M
N
O
D.H.W. recirculation kit (optional)
Connection for D.H.W. recirculation (optional)
Recirculation pump (optional)
D.H.W. recirculation control display (optional)
165
