ECO-COMBI 1
MULTI-HEAT ENERGY BUFFER WITH 316L STAINLESS STEEL D.H.W. CORRUGATED PIPE
APPLICATION
Heating hot water storage and D.H.W. production
MATERIAL
• BUFFER TANK: made in mild steel outside painted. There is no need of
any anti-corrosion treatment due to the fact that the buffer is in a closed
circuit without any adding air.
• D.H.W. STORAGE : 316L stainless steel corrugated pipe, suitable
drinkable water according to D. M. n. 174 dated 06.04.04
TECHNICAL DESCRIPTIONS
Multi-Heat Energy tanks EcoCombi 1 are used in units with a typically
discontinuous energy source for double use: heating system and sanitary
hot water system .
• Heating system with a biomass generator as energy source , combining
the possibility to produce hot water for sanitary use. In such case ,
storage heating volume allows the generator to regularly work , limiting
number of stops due to the inadeguate energy request of the heating
system. Moreover, it limits the emission of smoke and the creation of
corrosive condensate (smokes side).
• Sanitary hot water production systems for domestic and sanitary use
where heating water is stored. In this system , the high potentiality of
the Eco Combi allows to obtain a good production of hot sanitary water
even if temperatures of the primary system are not so high (i.e using
heating pumps as primary source and solar source as support)
The particular shape of the corrugated pipe is avoiding any problem
relating to the storage of sanitary hot water (less, stagnation,bacterium
etc ) and ensure high heating exchange performances.
INSULATION
NOFIRE® 100 mm soft polyester fibre 100% made of recyclable material,
with high Thermal insulation and Thermal conductivity: 0,039 W/mK.
Fire resistance class B-s2d0 according to EN 13501. PVC external lining
complete with top cover
WARRANTY
- Buffer tank: 2 years
- 316L stainless steel corrugated pipe for D.H.W. production: 5 years
See general sales conditions and warranty
ACCESSORIES AND SPARE PARTS : See page 216
PROMPT DELIVERY
NOFIRE®
INSULATION
1-5 days to dispatch
(delivery time excluded)
316L
STAINLESS STEEL CORRUGATED
PIPE FOR D.H.W. PRODUCTION
ECO COMBI 1 VC
Mod V
