EXTRA2 INOX
VAPORE
316 L STAINLESS STEEL CALORIFIERS WITH 2 EXTRACTABLE HEAT EXCHANGERS FOR STEAM GENERATOR
APPLICATION
Production and storage of sanitary hot water. Suitable for steam
generators.
MATERIAL
Stainless Steel 316 L suitable drinkable water according to D. M. n. 174
dated 06.04.04
HEAT EXCHANGER
1 stainless steel 316L heat exchanger suitable for steam power
INSULATION
NOFIRE® 50 mm soft polyester fibre 100% made of recyclable material,
with high Thermal insulation and Thermal conductivity: 0,039 W/mK.
Fire resistance class B-s2d0 according to EN 13501. PVC external lining
complete with top and flange cover.
CATHODE PROTECTION
2 magnesium anodes.
DRAIN
External confluence through drain pipe.
GASKET- FLANGE PLATE
Silicone gaskets suitable for alimentary use for max temperature up to
192 °C. Flange plate.
WARRANTY
- 5 years (316L stainless steel) - See general sales conditions and warranty
ACCESSORIES AND SPARE PARTS : See page 216
NOFIRE®
INSULATION
HEAT EXCHANGER SURFACE
INOX 316L
EXTRA 2 XXC VT VAPORE
Model
3000
4000
5000
HEAT EXCHANGER
STAINLESS STEEL
D.H.W. Storage: 316L STAINLESS STEEL
Heat Exchanger: 316L STAINLESS STEEL
Art. Nr.
Price €
3069052301008
14.864,00
3069052301009
20.123,00
3069052301010
25.331,00
Lower
2
[m ]
3
4
5
Middle
[m2]
3
4
5
316L
OK
EXCHANGERS
Model
PED
Lower heat Exchangers peformances calculated with primary Lower heat Exchangers peformances calculated with primary
circuit at 6 bar saturated steam and production of DHW from circuit at 3 bar saturated steam and production of DHW from
10° to 45°C
10° to 45°C
Output
DHW production
Ignition time
Output
DHW production
Ignition time
Middle
3000
4000
5000
Cat. I
Cat. I
Cat. I
[KW]
423
564
705
[l/h]
10393
13857
17321
[l/10']
5438
7031
9097
[min]
17
17
17
[KW]
341
455
568
[l/h]
8378
11171
13963
[l/10']
5102
6583
8537
[min]
22
21
22
Lower
3000
4000
5000
Cat. I
Cat. I
Cat. I
423
564
705
10393
13857
17321
4098
5349
6907
11
11
11
341
455
568
8378
11171
13963
3762
4902
6347
14
13
14
Accessories on request
“Easy Con G&
