LYNX Series 5000 - October 2013 October 2013 | Page 42
SDTV
HD 1.5G
HD 3G
SDTV
FIBER
HD 1.5G
HD 3G
RACK FRAMES
RACK FRAMES
R FR 5014 R FR 5012
Features
Features
Compact 19 inch 2 RU rack mount rack frame which can accommodate up to 10 modules, primary and
redundant power supplies plus the optional APPolo rack controller. Fan cooling is provided through the
front cover. The high quality stainless steel construction is fully EMC/FCC compliant. All racks are pre-wired
for the APPolo control system.
Note: This version is recommended when multiple higher power signal processing modules are used. This is the standard
choice for most system installations.
Description
R FR 5012 19” Rack Frame with Primary Power Supply (fan cooled)
6155025012
Option : R PS 5012 Redundant Power Supply
R PS 5012
Redundant Power Supply
(Primary Supply Included
2 RU Rack Frame for Series 5000 (No Fan Cooling)
Features
Compact 19 inch 2 RU rack mount rack frame which can accommodate up to 10 low power* modules,
primary and redundant power supplies plus optional APPolo rack controller. This rack is convection cooled
(no fans). The high quality stainless steel construction is fully EMC/FCC compliant. All racks are pre-wired for
the APPolo control system.
*Note: This version is recommended when multiple low power modules are used, e.g. Distribution Ampli?ers. Not
recommended for high power signal processing modules.
42
Ordering Information
Part #
Description
6155005014
R FR 5014 19” Rack Frame with Primary Power Supply (no cooling)
6155025012
Option : R PS 5012 Redundant Power Supply
Compact 19 inch 1 RU rack mount rack frame which accommodates 4 Series 5000 modules. Includes
primary power supply plus integrated LAN controller for use with the APPolo control system (software
included). Optional external power supply is available for redundant protection (R PS 5000)
Ordering Information
Ordering Information
6155005012
R FR 5013 R FR 5041
1 RU Rack Frame for Series 5000
2 RU Rack Frame for Series 5000 (Fan Cooled)
Part #
FIBER
R PS 5012
Redundant Power Supply
(Primary Supply Included
Part #
Description
6155505041
R FR 5041 1 RU Rack Frame with Primary Power Supply + LAN + Softwar e
6155012208
Option : R PS 5000 External Redundant Power Supply [Brick]
R PS 5000
External Redundant Power
Supply
(Primary Supply Included
2 RU Rack Frame for Passive Fiber Modules (No Power)
Features
Compact 19 inch 2 RU rack mount rack frame which can accommodate up to 12 passive ?ber optical
modules (OCM and OSP modules). This is a passive rack frame and rack requires no power. The OCM and
OSP Optical modules mount from the rear of the rack.
Ordering Information
Part #
Description
6155005013
R FR 5013 19” Rack Frame for Passive Optical Modules
