SOLID END MILLS
4fl
35°
FACE
MILLING
SHOULDER
MILLING
PLUNGING
EQUAL
90° 4 FLUTE, SHORT
DESIGNATION GRADE D1 D2 L1 L2 CATALOG #
E90 Z4 D01.0(04) L03.0(050) LT 40 1 4 50 3 M5005512
E90 Z4 D01.5(04) L05.0(050) LT 40 1.5 4 50 5 M5005513
E90 Z4 D02.0(04) L06.0(050) LT 40 2 4 50 6 M5005514
E90 Z4 D02.5(04) L08.0(050) LT 40 2.5 4 50 8 M5005515
E90 Z4 D03.0(04) L08.0(050) LT 40 3 4 50 8 M5005516
E90 Z4 D04.0(04) L11.0(050) LT 40 4 4 50 11 M5005517
E90 Z4 D05.0(06) L13.0(050) LT 40 5 6 50 13 M5005518
E90 Z4 D06.0(06) L16.0(050) LT 40 6 6 50 16 M5005519
E90 Z4 D08.0(08) L20.0(060) LT 40 8 8 60 20 M5005520
E90 Z4 D10.0(10) L25.0(072) LT 40 10 10 72 25 M5005521
E90 Z4 D12.0(12) L30.0(075) LT 40 12 12 75 30 M5005522
E90 Z4 D16.0(16) L40.0(100) LT 40 16 16 100 40 M5005523
CUTTING SPEED
p. 290
DOC / FEED
p. 291 - 302
155
