ALU MILLING
CUTTERS APGT
90°
Ap
d
D
L1
L
END MILL - APGT 1604
DESIGNATION
α 5 M2002966
5 M2002965
3 3 M2002968
15 3 3 M2002967
50 15 4 2.5 M2002970
90 15 4 2.5 M2002969
D d L L1 Ap Z
LT 731 W-W-D025/2 25 25 100 44 15 2
LT 731 WL-W-D025/2 25 25 220 90 15 2
LT 731 W-W-D032/3 32 32 110 50 15 LT 731 WL-W-D032/3 32 32 220 90 LT 731 W-W-D040/4 40 32 115 LT 731 WL-W-D040/4 40 32 220
CATALOG #
SCREW
KEY
M2000597
M2000602
d
L
Ap
90°
D
SHELL MILL - APGT 160408 PDTR
D d L Ap Z LT 731 M-W-D040/4 40 16 40 15 4 2.5 M2002971
LT 731 M-W-D050/5 50 22 40 15 5 α 2.2 M2002972
LT 731 M-W-D063/6 63 22 40 15 6 1.8 M2002973
LT 731 M-W-D080/7 80 27 50 15 7 1.4 M2002974
LT 731 M-W-D100/8 100 32 50 15 8 1.1 M2002975
LT 731 M-W-D125/9 125 40 63 15 9 0.8 M2002976
LT 731 M-D-D160/10* 160 40 63 15 10 N/A M2002977
DESIGNATION
*On Request
144
SCREW
KEY
CATALOG #
M2000597
M2000602
