Schnellwechsel-Einsätze mit Sicherheitskupplung, Größe 3
Quick change adaptors with safety clutch, size 3
Adaptateurs à changement rapide avec limiteur de couple, taille 3
Verwendung:
Zur Spannung von Gewindebohrern.
Für Rechts- und Linksgewinde. Ausführung
mit einstellbarer Sicherheits kupplung zur
Ver meidung von Gewinde bohrerbruch.
Application:
For mounting taps. For right-hand and left-hand
threads. Type with adjustable safety clutch,
which prevents the breaking of taps.
Application:
Pour le serrage de tarauds. Pour taraudage à
droite et à gauche. Modèle avec limiteur de
couple, qui prévient la casse des tarauds.
Bestell-Nr.
Order no.
Référence D d l 1 M DIN
16.13.14119 72 48 41 M14 16.13.16129 72 48 41 M16 16.13.181411 72 48 41 16.13.201612 72 48 16.13.2218145 72 16.13.2418145 72 16.13.272016 Schaft
Shaft
Queue Vierkant
Square
Carré
376 11 9,0
376 12 9,0
M18 376 14 11,0
41 M20 376 16 12,0
48 41 M22 376 18 14,5
48 41 M24 376 18 14,5
72 48 41 M27 376 20 16,0
16.13.302218 72 48 41 M30 376 22 18,0
16.13.332520 72 48 41 M33 376 25 20,0
16.13.362822 72 48 41 M36 376 28 22,0
Note:
Observation:
Bei Adaptern mit Sicherheitskupplung wird das Drehmoment entsprechend der Gewindegröße vor
Auslieferung eingestellt.
Quick change adaptors with safety clutch are supplied with a predefi ned torque, corresponding to the sizes
of the threads.
Les adaptateurs porte-tarauds à changement rapide avec limiteur de couple sont fournis avec un couple
préréglé, qui correspond aux tailles de fi letages.
