Schrumpffutter zum Spannen
ISO 12164-1 von HM und HSS Werkzeugschäften
( DIN 69893) HSK-A
Shrink chucks for mounting of solid carbide and HSS-tool shanks Mandrins de frettage pour le serrage de queues d‘ outils carbures de type HM et HSS
Verwendung: Zur Aufnahme von Werkzeugen mit Zylinderschaft.
Application: For mounting straight-shank tools.
Application: Pour le serrage d’ outils avec queue cylindrique.

4

ISO 12164-1( DIN 69893-1)
HSK- A ��≤ 0,003
G2,5 25.000 min-1 CAD
Bestell-Nr. Order no. Référence
HSK
d
A
D
D 1
l 1
l 2
A100.70.06.3
HSK-A 100
6
200
21
27
36
10
A100.70.08.3
HSK-A 100
8
200
21
27
36
10
A100.70.10.3
HSK-A 100
10
200
24
32
41
10
A100.70.12.3
HSK-A 100
12
200
24
32
47
10
A100.70.14.3
HSK-A 100
14
200
27
34
47
10
A100.70.16.3
HSK-A 100
16
200
27
34
50
10
A100.70.18.3
HSK-A 100
18
200
33
42
50
10
A100.70.20.3
HSK-A 100
20
200
33
42
52
10
A100.70.25.3
HSK-A 100
25
200
44
53
58
10
A100.70.32.3
HSK-A 100
32
200
44
53
62
10
A100.70.06.4
HSK-A 100
6
250
21
27
36
10
A100.70.08.4
HSK-A 100
8
250
21
27
36
10
A100.70.10.4
HSK-A 100
10
250
24
32
41
10
A100.70.12.4
HSK-A 100
12
250
24
32
47
10
A100.70.14.4
HSK-A 100
14
250
27
34
47
10
A100.70.16.4
HSK-A 100
16
250
27
34
50
10
Hinweis: Aufnahme für Induktiv-, Kontakt- und Heißluftschrumpfgeräte geeignet. Schafttoleranz bei Ø 6 – Ø 32 mm = h 6
Note: Toolholders suitable for induction-, contact- and hot air shrink units. Ø 6 – Ø 32 with h 6-tolerance
Observation: Porte-outils convenables pour machines à fretter par induction-, par contact-, ou par air chaud. Ø 6 – Ø 32 avec h 6-tolerance
l 1 = max. Einstecktiefe l 1 = max. clamping depth l 1 = max. profondeur d’ insertion
l 2 = max. Verstellweg l 2 = max. length adjustment range l 2 = max. course de réglage
