J. Eur. Opt. Society-Rapid Publ. 22, 39( 2026) grating a Si 3 N 4 / SiO 2 anti-reflection coating, surface reflectance was reduced to nearly zero at 1.55 lm, resulting in a responsivity enhancement of approximately 36 %( from 0.60 to 0.82 A / W). The device also exhibits low capacitance( 9.2 pF at �5 V) and a high breakdown voltage( �82.5 V), indicating its suitability for high-speed, lownoise, and wide dynamic range applications. Overall, this study demonstrates that precise control of barrier composition, doping, and layer thickness enables simultaneous optimization of electrical and optical performance in nBn architectures [ 39 ]. The presented design achieves an excellent trade-off between ultra-low dark current and high responsivity under low-bias operation, making it a strong candidate for next-generation short-wave infrared photodetectors operating under low-photon-flux and high-sensitivity conditions.
Funding This research received no external funding.
