FOCUS ON STAMPING
PRESSING FOR ACTION
A sample of stamped parts for electric vehicles from FIUKA on the Minster EV press .
A selection of the latest stamping technologies , processes , tooling and press models come under the spotlight in this article .
“ We highlight an alphabetical selection of the latest new global stamping and pressing innovations .”
Metal stamping is a manufacturing process used to transform metal sheets ( often called “ blanks ”) into different shapes . It uses cold forming techniques , which means that no heat is used to reshape the metal . Instead , the metal is placed between dies and stamping presses that shape and shear it by applying pressure . A high-speed process , metal stamping is one of the fastest and most cost-effective solutions for manufacturers in need of high-quality components ( especially for large-quantity orders ).
Stamping presses utilise the force of a moving ram to transmit force , or an amount of tonnage , to specific tooling to achieve a product ’ s final shape , often with little or no scrap and , whenever possible , with minimal operator intervention . Stamping dies are the tools that shape and cut sheet-metal parts .
There are four main types of metal stamping processes : progressive die stamping , transfer die stamping , four-slide stamping and fine blanking . Within each of these stamping processes , various stamping techniques are employed . These can include punching or perforating ( to remove scrap pieces from the metal sheet as a punch enters the die ); blanking ; bending ; coining ( leaving an impression in a metal workpiece ’ s surface ); flanging ( using a flange or flare tool to create a joint in the metal sheet which connects multiple components ) and embossing . Hot stamping entails heating the material until it becomes malleable . It is subsequently subjected to a formation and rapid cooling process to produce a transformed and hardened material .
Some of the most common types of metal stamping machines include mechanical , hydraulic and servo presses that are fitted with multiple dies to cut and shape the sheets of stainless steel and metals such as aluminium , zinc and copper . Better control , greater speed and versatility , shorter cycle times and higher energy savings are just some of the hallmarks of the latest technologies .
In this article , we highlight an alphabetical selection of the latest new global stamping and pressing innovations .
Better control , greater speed and versatility , shorter cycle times and higher energy savings are just some of the hallmarks of the latest technologies
In the spotlight
AIDA will debut its NSX mechanical stamping press at FABTECH 2023 in Chicago , USA , this September . This newly designed ; two-point ; 110-metric-ton unitised frame press is capable of speeds ranging from 120-300 strokes per minute . It features a zero clearance ; lubrication-free ; eight-point roller slide guide system and dual counter-rotating eccentric shafts . Press and die integrity are protected by AIDA ’ s metal seal type Hydraulic Overload Protection ( HOLP ) at 10 milliseconds to zero pressure .
AIDA is a global specialist in the design ; manufacture ; sale ; service and support ; refurbishment and modernisation of metal stamping presses and metalforming automation equipment . AIDA servo and mechanical stamping presses range in capacity from 35 to 4,000 tons ; from a few to 800 strokes per minute ; from gap frame to straightside ; high-speed to cold forging , transfer and progressive die ; material handling and coil-feeding equipment .
Two product lines that are dedicated to the production of motor laminations are the AIDA HMX Series and AIDA MSP Series presses . The AIDA MSP press enables users to produce motors such as EV motors , HEV motors and energy-efficient home appliance motors .
AIDA ’ s new DSF-NE2 presses are equipped
AIDA ’ s new DSF-NE2 servo press .
with their own low-RPM , high-torque servo motor for metalforming applications . Its DSF-TE4 servo transfer presses ( double-column split presses designed for
