PRODUCT REVIEWS
Schiavi Macchine will showcase two hybrid press brakes at EuroBLECH .
Sheet-metal bending
At this year ’ s EuroBLECH exhibition in Hanover , Germany ( 25-28 October 2022 ), Schiavi Macchine will display a 170-ton HFBx hybrid press brake ( 3m , eight axes , with 800mm large opening and 500mm stroke ).
“ It is ideal for bending complex profiles and can reach speeds of up to 300mm / s ,” the Italian bending specialist told ISMR .
The second press brake on its stand will be a small 50-ton Hybrid BSTs ( 1.2m , six axes ) for the rapid bending of small components . This press brake consumes 0.6-0.7kW / h of energy and offers speeds of up to 250mm / s .
“ Our Atlas CNC control will feature on both press brakes . It automatically generates the entire bending program , including tooling set-up ,” added the manufacturer . “ We will
The Compact Tower .
also present our laser automation line by introducing the Compact Tower , which enables a laser-cutting system to run without operators .”
Meet Schiavi Macchine International on stand F86 in Hall 12 at EuroBLECH 2022 . n
The spray also adheres to contaminated surfaces .
Scanning spray
Large items , such as yachts , aircraft and cars ( with areas that are difficult to access and tricky surfaces ), are usually measured with handheld scanners or portable laser trackers . Often , the aim is to optimise speed and fuel consumption . If the surfaces are shiny or transparent , these must first be made visible to the scanner . This is done with scanning sprays which mat the shiny surfaces .
The AESUB green scanning spray designed for large-sized components is now available for this purpose . It is applied quickly using a spray gun . The applied spray layer sublimates automatically after a few hours , so the sprayed parts do not have to undergo time-consuming and / or expensive cleaning .
“ After six hours , the layer sublimates and the object and its environment are completely clean again . No cleaning is required ,” said the manufacturer .
With the ‘ vanishing ’ AESUB scanning sprays , parts can be sprayed directly in the area being measured . Within a few hours , a thin , white layer generates high contrast values . The layer thicknesses are between 1 µ and 15 µ m . The matting layer is touch-dry , so that the parts can also be touched and repositioned during the scanning process . Reference points , confirmed the manufacturer , can be placed directly on the layer . n
. aesub . de
Productivity in focus
Messer Cutting Systems ’ product range includes oxyfuel , plasmaand laser-cutting systems from hand-guided machines up to special machines for shipbuilding . This encompasses machines and equipment for oxyfuel welding ; cutting ; brazing ; soldering and heating . Spare parts ; repairs ; retrofit ; maintenance / service ; environmental technology and inhouse software solutions are also offered .
At EuroBLECH 2022 in Hanover , Germany , it will focus on new levels of productivity with ELEMENT ( its latest plasma bevel technology ) up sales quotes ; nesting plans ; production and ELEMENT L ( a new , flexible solution for planning ; material handling ; machine controls precision laser bevel cutting , including XXL and business process analysis ) will be shown sheet ). It will also demonstrate its latest live . The digital network of machines and solutions for digitisation in production and systems will provide the relevant production Industry 4.0 . The entire process ( from setting data in real-time .
“ Besides the ELEMENT 400 , with the latest plasma bevel technology , we will also present our new laser machine , ELEMENT 400 L . It features a remarkably high level of dynamics , the latest laser technology and the ability to handle XXL sheets economically .
Equipped with the new Bevel-U bevel cutting head , Laser Nozzle Control ( LNC ) and our easy-to-operate Global Connect control , it ensures maximum productivity as well as optimum usability . The Bevel-U creates bevel parts which are precise and repeatable , a great benefit in edge preparation for the robotic welding process ,” it explained .
Meet the company on stand D138A in Hall 13 at EuroBLECH . n
:// uk . messer-cutting . com / euroblech
