PRODUCT REVIEWS

Rapid clamping system for short set-up times

ROEMHELD’ s new rapid clamping system, Flexline R, is a sturdy solution for the automatic clamping of dies of different sizes on the press ram. Clamping takes place via hollow piston cylinders.
“ The new product is based on the Flexline system and has been further developed specifically for higher loads and demanding operating conditions. It is equipped with a stainless-steel, pull-push chain, reinforced stops, additional query options and improved emergency operation. Numerous variants can be configured to suit individual customer requirements. Flexline R is suitable for all applications with frequent die changes, especially for use in automated press lines,” ROEMHELD told ISMR.
At the heart of the new design is a welded stainless-steel, pull-push chain. It replaces the previous version made of plastic and is designed for stability and durability, even under harsh conditions. The chain case, all brackets and the sheet metal parts are also made of reinforced stainless steel and are designed for robust application scenarios.
“ The new system also offers improved position monitoring: a magnetic field sensor detects the parking position, while the inductive sensor reports the position of the clamping element on the die. Optionally, the end position of the chain can also be queried using a sensor system integrated in the chain case. Reinforced brackets for position monitoring are also new for maximum operational safety. An emergency release on the drive motor provides additional safety in the event of an accident. If necessary, the die can be released manually,” explained the manufacturer.
Flexline R is available with two adjustment tracks, 660mm and 1100mm, and can be combined with four different clamping elements. Depending upon requirements, single or double-acting hollow piston cylinders with up to 104kW clamping force and operating pressures of 245 or 400 bar are available. The motor can be mounted on the left or right. The clamping positions are also freely selectable.
Ease of use
ROEMHELD also highlighted the system’ s ease of operation. The electromechanical driven push chain automatically moves the hollow piston cylinder attached to the system from the park position to the die edge and back again. At the same time, it serves as a hydraulic and electric line to the clamping element. This eliminates the need for a separate energy supply system. It is guided in the T-slot of the machine and is compatible with sizes of 28mm and 36mm as well as 1 1 / 16”.
“ Thanks to its compact design, low weight and the use of low-maintenance modules, Flexline R is configured to meet the demanding requirements of modern press lines. The modules are easy to replace, which simplifies servicing and reduces downtimes. The electrical interface is via Harting connectors with IP65 protection. An individual colour and brand design is available as an option,” concluded ROEMHELD. n
www
. roemheld. com

New release for 3D robot vision solution

Pickit 3D, a provider of 3D robot vision solutions, has announced the release of Pickit 3.5, featuring six new additions to its second-generation, high-definition, 3D-vision camera range. This expansion enables the Pickit 3D platform to address a wider array of applications.
“ The 3D robot vision market is experiencing rapid growth, as it allows robots to execute tasks with unparalleled flexibility, efficiency and safety while reducing costs. [ Our adaptable 3D robot vision platform facilitates ] numerous automation processes such as bin picking, depalletisation, assembly and surface treatment,” explained Pickit 3D.
The new 3.5 release has been designed as an easy-to-use, camera- and robot-agnostic solution. New cameras cater to diverse needs from handling small, shiny and even transparent parts to dealing with extra-large objects and managing multiple Euro palletsized surfaces. Key features of the Pickit 3.5 release include:
■ Six new cameras, offering higher precision: The M-HD2 and L-HD2 bundles now offer multiple cameras based upon either structured light or laser technology.
■ Expanded applications: Enhanced camera performance supports more applications with improved features.
■ Up to three times larger Field of View( FOV): Laser triangulation cameras now utilise the entire scanning pyramid, drastically expanding the FOV for applications involving large objects, multiple bins or broader work areas.
■ Point clouds: Higher resolution and cleaner point clouds with fewer missing points improve object recognition and precise picking, especially for small and shiny parts.
Pickit was founded in 2016 as a product spinout from Intermodalics, an organisation that develops software for robots. Pickit’ s headquarters are in Leuven, Belgium, and it has sales offices in Germany, the U. S. and South Korea. n
www. pickit3d. com
