the design , construction , and operation of oil and gas facilities . Conducting HAZOP analysis helps companies comply with these regulations and avoid penalties or legal action .
Cost savings : This can identify opportunities for cost savings by identifying potential design flaws or inefficiencies in the process systems . This can lead to improvement in the process design , resulting in reduced operating costs and increased productivity .
Continuous improvement : This is a continuous process that can be carried out throughout all oil and gas facility phases . It helps operators identify areas for improvement in the design , operation , and maintenance of the facilities , leading to continuous improvement in safety , efficiency , and reliability .
Classic HAZOP Case Study
The Piper Alpha disaster is one of the worst offshore oil rig accidents in history . Piper Alpha was a tragic incident on July 6 , 1988 , on the Piper Alpha oil rig in the North Sea , resulting in the deaths of 167 workers . ( Swuste et . al , 2018 ) The incident was caused by a gas leak that led to a catastrophic explosion and fire , which destroyed the platform . Following the Piper Alpha disaster , HAZOP analysis has become essential to safety management systems in offshore oil and gas operations .
The Piper Alpha disaster is often used as a lesson in major accident hazards because it highlights the importance of identifying and mitigating potential hazards . The disaster was caused by human error , malfunctioning equipment , and weak safety measures . Some of the issues that could have been identified during a HAZOP study include : 1 . Inadequate isolation of the gas supply lines . 2 . Lack of automatic shutdown systems . 3 . Inadequate fire protection measures . 4 . Poor maintenance practices . 5 . Inadequate training and communication between the workers .
The HAZOP team , which typically consists of multi-disciplinary professionals who identify hazards and assess risks associated with activities on oil rigs , plays a crucial role in ensuring the safety of personnel and equipment . In the aftermath of the Piper Alpha tragedy , it became clear that offshore oil and gas companies needed to adopt a more systemic approach to hazard analysis and risk assessment .
A HAZOP study is a vital tool for achieving sustainable industrial development and should be considered an essential component of any industrial safety programme . It is an important part of a safety analysis and control systems process . One approach to conducting a HAZOP study is to base the analysis on accident experience . This involves analysing past accidents or incidents that have occurred in similar systems or processes to identify potential hazards and areas for improvement . This can help to identify specific scenarios or sequences of events that can lead to accidents and identify ways to prevent or mitigate these scenarios in the future . It can also help to identify and evaluate the effectiveness of the controls that are in place to protect the safety of workers and the environment . In addition , a HAZOP study can also help reduce the likelihood of an accident by identifying areas where a system is not operating properly or where the equipment may fail . In some cases , this information can be used to design safer equipment or make improvements to the design of a system .
Overall , the benefits of implementing a HAZOP study are numerous and far-reaching , from ensuring worker safety to protecting the environment and surrounding communities , to improving operational efficiency and reducing costs associated with accidents or downtime .
Typical HAZOP Examination Session for the Oil & Gas Industry
1 . Describe the Overall Process of Intent The HAZOP study involves breaking down the plant into smaller sections called nodes , each analysed for deviations from the design intent . The overall process intent defines how the particular process was intended to operate . The design intent should specify how the node will be operated under all system operating conditions specified by parameters such as pressure , temperature , flow rate , and level .
