UTILITY VEHICLES
maximum outside turning radius of 7,100 mm,
increased basic machine weight of 19,000 kg, and
Volvo Penta TAD870VE EU Stage IV, Tier 4f,
CANMET, MSHA engine developing 160 kW.
All these grader models have advanced
automatic hydraulically operated blade shock
absorbers to give the machines increased ability
to avoid impact damage normally associated with
hard mining conditions. It means that the middle
blade moves up to 10 cm upwards without
jumping the motor grader itself when driven over
materials too hard to grade down at the desired
level, for example, rocks that protrude over the
road level. When needed, the system can be
switched off. IM
A Veekmas FG 7 C grader at
work underground
facilitated. Operator friendliness has been
improved thanks to new controls and joysticks
which are located ergonomically.
The FG 5 C has a height of 1,990 mm,
maximum outer turning radius of 4,900 mm with
a front blade, total weight of 9,000 kg, and three
engine alternatives: Deutz TCD 3.6 L4 EU Stage
IV, EPA Tier 4 with 90 kW; Mercedes-Benz OM
904 LA EU Stage IIIA, EPA Tier 3, MSHA with 90
kW; Deutz BF4M 2012 EU Stage II with 75 kW.
The somewhat larger Veekmas FG 7 C has a
height of 2,460 mm, maximum outer turning
radius of 4,950 mm with a font blade, total
weight of 9,800 kg, and Deutz TCD 3.6 L4 EU
Stage IV engine, EPA Tier 4 developing 90 kW or
alternatively Mercedes-Benz OM 904 LA EU Stage
IIIA, EPA Tier 3, MSHA developing 90 kW, Deutz
BF4M2012 EU Stage II, EPA Tier 2, MSHA
developing 75 kW.
The FG 15 C, the largest machine UG motor
grader model has a height of 2,760 mm,
Pictured here, Pillar Innovations’ EMU-ALR
(electrically powered and here is ambulance
format) is a modified version of the popular
EMU-LR (Low Rider), designed for 1.14 m seams.
The EMU-ALT is available for mines with a height
of approximately 1.8 m and above.
