UTILITY VEHICLES
The company says that the CF240 is also designed with the mechanic in mind. The cab tilts forward to allow full access to the engine. Components that need regular service are easily accessible and can be reached by any average person standing at ground level.
Getman focus on concrete spraying and transport
Getman Corporation continues with the development of its wide range of product lines, and with the most recent focus Derek Getman, VP Business Development, told IM being on an expanded offering in its concrete spraying and transport line, introducing a new 9 yd 3 Concrete Agitator to its existing series of remixers and agitators.“ This larger capacity machine enables more efficient and lower cost movement of concrete underground to support ground support activities. Shipment of this machine has begun in North America and will begin shortly in other parts of the world.”
Getman has also announced the launch of its A64 Water Cannon. This machine utilises a high pressure, high flow water jet to help clear blockages in stopes and draw points, creating a safe and effective means of ensuring proper ore flow. Additionally, Getman says it has maintained a focus on improving productivity across its product lines while lowering lifetime operating costs.“ Recent examples include the launch of Kessler axle availability for all Getman machines, as well as major component redesigns such as our S3120 Mechanical Scaler power train and our Explosives Charger boom and basket. We continue to focus on the development of products that improve safety and facilitate more efficient production in underground mining operations. We are especially focused on technologies and advancements in the areas of sprayed concrete for ground support, as well as technologies that support the industry trend toward underground mass
The Manitou MT-X 1030S is fitted with a Powershuttle torqueconverter transmission gearbox with four speeds, enabling it to reach a speed of 27 km / h
mining methods.”
New Manitou high performance mining telehandler
The new Manitou MT-X 1030S telehandler model, shown here in the attached pic in an underground mining application, has a lifting capacity of 3 t and is equipped with a boom that can reach a lifting height of 10 m. A highperformance machine with a 101 hp engine, the company says“ it provides maximum operator security in a mining environment thanks to the fail-safe braking and steering system deployed in the event of breakdown, optional engine fire suppression and an ultimate electrical protection system.”
This model is fitted with a Powershuttle torque-converter transmission gearbox with four speeds, enabling it to reach a speed of 27 km / h.“ Stabilisers also ensure perfect safety when handling heavy loads, and the operator can attach various accessories, such as the EN280-standard access basket. The model also offers 360 ° visibility thanks to the four cameras positioned on the front, right-hand side and rear of the MT-X 1030S, and comes with an exhaust-fumes purification and dilution system as standard to
UNDERGROUND
MINING EQUIPMENT WORLDWIDE reduce pollutant gas emissions.
With its expert teams and specially designed range of products and services, Manitou Group says it is“ reinforcing its leading position among the main handling-equipment manufacturers operating in the mining industry.”
A smoother ride from DUX
DUX Machinery recently developed a patentapplied operator compartment suspension system for its haulage trucks, which is now also available on its S1-Series utility trucks. The system features an elastomer strut, and adjustable shock absorbers and front anchor pins on rubber bushings, designed to withstand the rigours of severe underground mining conditions by softening impact loads and vibration
With over 45 years of experience, DUX offers a full range of products designed to meet the needs of mining and tunnelling projects worldwide.
Contact DUX today for field-proven underground haulage, utility and scaling solutions.
The Getman Explosives Charger Boom operating in an underground silver mine. Getman will roll out a new boom for its Explosives Charger Range in 2017
DUX MACHINERY CORPORATION 615 Lavoisier, Repentigny, QC Canada J6A 7N2
+ 1( 450) 581-8341 www. duxmachinery. com
MARCH 2017 | International Mining 23
