UNDERGROUND DRILLING
automatic control and reliability, utilising high
quality components that are sourced worldwide,
including Montabert drifters.
“For many years, Huatai Mining has served
many Chinese big state-owned mining groups
such as China National Coal Group, Laiwu
Shandong Iron & Steel Mineral Company, China
National Gold Group Corporation, China Coal
Construction Group Corporation, Shenhua Group,
CICC South of the Five Ridges, China Steel Group,
SINOCHEM and CRCC.”
Recently, to respond to China’s ‘Belt and Road
Initiatives’ policy exports have been made to
Russia, Turkey, Iran, Vietnam, Syria, India,
Philippines, Zimbabwe, Kazakhstan, Tajikistan and
other countries. The Huatai Mining jumbo is
already relatively well known in the underground
mining and tunnelling industry. Models include the
12.5 t HT81 hydraulic drilling jumbo which is
mainly used for tunnel construction in metal mines
and other underground engineering projects.
“Equipped with one boom with an advanced
hydraulic rock drilling system and anti-jamming
mechanism, ensures rapid drilling speed and high
efficiency. This jumbo features great mobility, a
short turning radius and strong gradeability, thus
can improve the working environment and ensure
efficient, high quality development.” This model
has a Montabert HC50 drill with hole depth of up
to 3,900 mm. Its dimensions are 11,050 mm/1,850
mm/2,340 mm (LxWxH).
“Huatai Mining has
made mechanisation
for mining into reality,
replacing manual
labour, thanks to its
reliable, intelligent
drilling and range of
mining, bolting and
safety equipment. It
has changed heavy-
loaded and high risk
operations into safer,
more productive and
more economic ones.”
Established in 1992,
Jiangxi Siton
Machinery Manufacturing Co Ltd in Pingxiang,
Jiangxi Province, is a professional manufacturer
of underground mining and tunnelling
equipment, such as drilling jumbos, mucking
loaders, LHDs and underground trucks, concrete
spaying equipment and underground
transportation equipment (shuttle cars and rail
wagons). Siton told IM that it has exported
equipment to over 30 countries, including Russia,
Norway, Croatia, Iran, Lebanon, Colombia, Peru,
Chile and several countries in southeast Asia.
One successful case saw a rubber wheeled
single boom jumbo drilling of model DW1-31
delivered to Shahin Mining Co Ltd in Iran, which
is a lead-zinc operation. The roadway included a
Adding Value.
Delivering Results.
Engineering and Environmental Specialists
From geotechnical engineering, hydrogeology, and
water management to environmental assessments
and renewable energy integration, our global team of
engineers and scientists has extensive expertise to
help you in advancing your project through all stages
of mine development.
Mining | Power | Water Resources | Infrastructure
www.knightpiesold.com
The SITON DW1-31 single boom runner wheeled
drilling jumbo in Iran
main ramp with about a 5 m width and 4.5 m
height, with the extraction tunnel also having
same dimensions (cross section area is about 20-
22 m 2 ), a very high rock hardness of more than
100 MPa, and a 20% slope. This particular
machine has a Montabert HYD300 drill as
standard, or a HC50 as an option. It drills hole
diameters of 36-102 mm and is also equipped
with HELAC rotary actuators with high rotation
torque. Other models include the single boom
DW1-90 with HC109 drill as standard and HC110 as
an option; and the double boom DW2-50 with
HC50 drill as standard and HC109 as an option. IM
