GEODYNA® RANGE
3D SAPE WHEEL BALANCERS
geodyna 6300-2P - EEWB511BPB1
Digital multi plane motorised wheel balancer with
LCD display and fast power clamp.
Scope of application:
Franchised dealers, garages and tyre shops with
medium to high tyre service volume.
Features
• Power clamp - wheel is locked to shaft
automatically
• VPM (virtual plane measuring) - enhanced
measuring to give higher accuracy results
• Automatic start of measurement when
hood closed & wheel stopped at the
end of spin cycle orientation at position
weight is required
• Wheel rim illuminated
• Robust 40mm shaft
• 5 different options for weight positioning
on wheel
• 3D SAPE - Automatic entry of wheel
diameter, width and wheel distance.
• Guided weight positioning in Alu mode
with auto stop (patented GeodataTM
arm)
• Split weight mode - Hide weights
behind wheel spokes for more appealing
cosmetic finish
• Tyre matching mode - optimise tyre to rim
so using less weights
Te c h n i c a l S p e c i f i c a t i o n
Shaft diameter
40 mm
Measuring speed
200 rpm
LCD
Rim width
1 - 20"
Rim diameter
8 - 25"
Wheel width max.
530 mm
Wheel diameter max.
950 mm
Wheel weight max.
70 kg
Dimensions (HxWxD)
1375 x 1365 x 1200 mm
Power Supply
200-240V 1ph 50 / 60 Hz
Machine weight
w w w. s n a p o n - e q u i p m e n t . c o . u k
43 - 116 mm
Display / Monitor TFT Monitor
• Tapered shaft
Rim centre bore diameter
153 kg
