Tabla 4
Comparativo del incremento para los diseños ortogonales.
4. Conclusiones
A partir de los resultados obtenidos se comenta lo siguiente:
● Los mejores resultados de este trabajo fueron encontrados en los arreglos ortogonales.
● El aumento en la fuerza máxima en los arreglos ortogonales fue mayor al 120 % respecto al metal base. Esto permitiría reforzar zonas sobre láminas que mejoren el desempeño localizado.
● El incremento en la fuerza máxima depende de la masa adicionada por parte de la manufactura aditiva, pero a su vez, depende también del arreglo y donde se esté aplicando la fuerza.
● Existe un efecto significativo en el modo de transferencia y en la parametrización establecida de modo que esta puede ser optimizada.
● La microestructura principal fue mayormente martensita en la zona afectada por el calor y ferrita en la zona de fusión de tipo columnar dendrítico.
5. Referencias
[ 1 ] C. M. M. V. R. D. T. A. R. T. G. S. J. O. J. G. Lopes, « Effect of milling parameters on HSLA steel parts produced by Wire and Arc Additive Manufacturing( WAAM)», Journal of Manufacturing Processes, vol. 59, pp. 739-749, 2020.
[ 2 ] S. P. M. S. B. V. Prabhakaran B, « Mechanical and Metallurgical Characteristics of Wire-Arc Additive Manufactured HSLA Steel Component Using Cold Metal Transfer Technique », Additive Manufacturing Frontiers, vol. 3, 2024.
[ 3 ] Y. C. L. J. X. Y. S. K. M. G. B. Jie Song, « Numerical study of temperature and cooling rate in selective laser melting with functionally graded support structures », Additive Manufacturing, vol. 24, pp. 543-551, 2018.
[ 4 ] S. S. V. P. S. A. K. P. Karunakaran, « Low cost integration of additive and cooling rate in selective laser melting with functionally graded support structures », Additive Manufacturing, vol. 24, pp. 543-551, 2018.
[ 5 ] F. V. A. S. J. B. A. L. E. Aldalur, « High deposition wire arc additive manufacturing of mild steel: Strategies and heat input effect on microstructure and mechanical properties », Journal of Manufacturing Processes, vol. 58, pp. 615-626, 2020.
[ 6 ] S. G. A. M. F. M. S. W. Philip Dirisu, « Analysis of fracture toughness properties of wire + arc additive manufactured high strength low alloy structural steel components », Materials Science and Engineering, vol. 765, 2019.
[ 7 ] Z. P. D. C. H. L. Donghong Ding, « A multi-bead overlapping model for robotic wire and arc additive manufacturing( WAAM)», Robotics and Computer Integrated Manufacturing, pp. 101-110, 2015.
[ 8 ] M. M. T. J. G. H. Nabeel Ahmed Siddiqui, « Heat sources in wire arc additive manufacturing and their impact on macro-microstructural characteristics and mechanical properties – An overview », Smart Materials in Manufacturing, vol. 3, 2025.
[ 9 ] P. K. M. A. W. L. G. Jiachi Yang, « Simulation and prediction of residual stresses in WAAM-strengthened I-sections », Structures, vol. 69, 2024.
[ 10 ] P. C. W. J. O. C. S. M. J. R. F. S. S. Daniel Delgado Camacho, « Applications of additive manufacturing in the construction industry – A forward-looking review », Automation in Construction, vol. 89, pp. 110-119, 2018.
[ 11 ] T. S. R. M. P. Oliveira, « Revisiting fundamental welding concepts to improve additive manufacturing: From theory to practice », Progress in Materials Science, vol. 107, 2020.
[ 12 ] A. S. M. M. J. G. I. T. A. L. Teresa Artaza, « Wire Arc Additive Manufacturing of Mn4Ni2CrMo Steel: Comparison of Mechanical and Metallographic Properties of PAW and GMAW », Procedia Manufacturing, vol. 41, pp. 1071-1078, 2019.
[ 13 ] S. G. S. Y. D. M. Yanli Zhu, « Forming characteristic analysis in twin tungsten electrode – Wire electrode indirect arc based additive manufacturing », Vacuum, vol. 232, 2025.
[ 14 ] B. K. R. P. M. G. S. A. Sandeep O S, « Influence of build direction on the corrosion behavior of Wire arc additively manufactured SS 304L », Materials Letters, vol. 383, 2025.
[ 15 ] F. R. T. L. J. d. S. D. B. d. A. R. P. R. A. S. Fernando Matos Scotti, « Thermal management in WAAM through the CMT Advanced process and an active cooling technique », Journal of Manufacturing Processes, vol. 57, pp. 23-35, 2020.
[ 16 ] J. A. E. M. C. C. P. M. N. G. G. C. William Hackenhaar, « Effects of different WAAM current deposition modes on the mechanical properties of AISI H13 tool steel », Welding in the World, vol. 66, p. 2259 – 2269, 2022.
[ 17 ] S. C. T. K. D. V. K. Pranjal Shukla, « The influence of GMAW correction parameters on stabilizing the deposition characteristics for wire arc additive manufacturing », Journal of Manufacturing Processes, vol. 90, pp. 54-68, 2023.
[ 18 ] N. K. M. V. A. W. Y. A. S. Jignesh Nakrani, « Viability of WAAM for fabrication / repair of SS316: Fatigue crack growth behavior for varied notch locations in the vicinity of WAAM-substrate interface », Theoretical and Applied Fracture Mechanics, vol. 133, 2024.
[ 19 ] L. Gardner, « Metal additive manufacturing in structural engineering – review, advances, opportunities and outlook », Structures, vol. 47, pp. 2178-2193, 2023.
[ 20 ] X. R. J. H. Z. Z. Li Suna, « Numerical investigation of a novel pattern for reducing residual stress in metal additive manufacturing », Journal of Materials Science & Technology, vol. 67, pp. 11-22, 2021.
[ 21 ] Z.(. P. D. C. H. L. Donghong Ding, « A tool-path generation strategy for wire and arc additive manufacturing », The International Journal of Advanced Manufacturing Technology, vol. 73, pp. 173-183, 2014.
[ 22 ] P. C. S. G. J. M. Jialuo Ding, « Thermomechanical analysis of Wire and Arc Additive Layer Manufacturing process on large multi-layer parts », Computational Materials Science, vol. 50, pp. 3315-3322, 2011.
[ 23 ] Lincoln Electric, « Alambres para MIG », [ En línea ]. Available: https:// www. lincolnelectric. com / es-MX / Products / superarcl56 _ gmaw. [ Último acceso: Enero 2025 ].
[ 24 ] T. N. T. S. Y. T. Y. I. K. O. Naoki Yamaguchi, « Nanotwinning grain refinement induced by micro-needle peening in arc-welded ultra-high strength steel sheet », Materialia, vol. 38, 2024.
