Fittings
72-1888
83-2055
72-1316
873188
Nipples & Reducing Nipples
Part Number
Description Materials Max. Working
Pressure
Inlet
Outlet
HIGH PRESSURE (continued)
6
84-509 Nipple 303 s.s. 3000 psi 1/4”nps(m) 1/16”npt(m)
72-2322 Nipple 303 s.s. 3000 psi 1/4”npt/nps(m) 5/8”-24 UNEF-2A
101-1772 Reducing nipple 316 s.s. 5000 psi 1/4”nps(m) 1/8”npt(m)
72-1888 Reducing nipple Steel pltd 6000 psi 1/4”nps(m) 3/8”nps(m)
72-988 Reducing nipple 303 s.s. 4500 psi 1/4”nps(m) 3/8”npt(m)
72-798 D.M. Nipple 303 s.s. 4500 psi 3/8”nps(m) 3/8”nps(m)
72-1933 Reducing nipple 303 s.s. 5000 psi 3/8”npt(m) 1/2”nps(m)
83-2055 D.M. Nipple 303 s.s. 4500 psi 3/8”npt(m) 3/8”nps(m)
72-998 D.M. Nipple Steel pltd 3000 psi 3/8”npt(m) 3/8”npt(m)
SSP-459 D.M. Nipple 316 s.s. 6000 psi 3/8”npt(m) 3/8”npt(m)
237-266 D.M. Nipple Steel 6000 psi 1/2”npt(m) 1/2”npt(m)
237-374 Reducing nipple Steel 6000 psi 1/2”npt(m) / nps(m) 3/8”npt(m) / nps(m)
72-1316 Reducing nipple Steel pltd 4000 psi 1/2”npt(m) 3/4”npt(m)
41-1235 D.M. Nipple 303 s.s. 2500 psi 1/2”nps(m) 1/2”npt(m)
72-1770 D.M. Nipple 303 s.s. 2000 psi 3/4”npt(m) 3/4”nps(m)
72-1102 D.M. Nipple Steel pltd 4000 psi 3/4”npt(m) 3/4”npt(m)
101-713 D.M. Nipple Steel, 3 1/2” long 5000 psi 3/4”npt(m) 3/4”nps(m)
41-28090 Reducing nipple Steel pltd 6000 psi 3/4”npt(m) 1/2”npt(m)
72-1981 D.M. Nipple Steel pltd 3500 psi 1”npt(m) 1”nps(m)
873188 Reducing nipple Steel pltd 6000 psi 1”npt(m) 1/2”npt(m)
N/R = Non-Rated • Pltd brass = Plated brass, chrome • S.S. = Stainless steel
Galv. = Galvinized steel • Steel pltd = Plated steel, cadmium or zinc • Poly = Polypropylene plastic
6-6
