Fittings
SSP-8217-ZN
Swivel Adapters (Straight)
Part Number Description Materials
SSP-8217-ZN Swivel adapter Steel pltd
103-1238 Swivel adapter s.s.
20-4281 Swivel adapter Steel pltd
20-4284 Swivel adapter 20-4283 Swivel adapter PLH-6SN-6TSS 0114-016058
Max. Working
Pressure
Inlet Outlet
4000 psi 1/4”nps(f) 1/4”npt(m)
4000 psi 1/4”npt(m) 3/8”nps(f)
4000 psi 3/8”npt(m) 3/8”nps(f)
Steel pltd 3000 psi 3/4”npt(m) 3/4”nps(f)
Steel pltd 3500 psi 1/2”npt(m) 1/2”nps(f)
Swivel adapter s.s. 250 psi 3/8”nps(m) 3/8”nps(f)
Swivel adapter s.s. 7250 psi 1/4”bspt(m) 3/8”BPS(f)
83-1935, 102-2126
6
Swivel Unions
Part Number Description Materials Max. Working
Pressure Inlet Outlet
72-1253 Swivel union Steel pltd 4000 psi 3/8”npt(f) 1/4”nps(f)
83-1935 Swivel union Steel pltd 4000 psi 1/4”npt(f) 1/4”nps(f)
N/R = Non-Rated • Pltd brass = Plated brass, chrome • S.S. = Stainless steel
Galv. = Galvinized steel • Steel pltd = Plated steel, cadmium or zinc • Poly = Polypropylene plastic
