Contactors
Water Level Control Systems
Electronic Water Level
Control Systems
Ideal for steam tables, dishwashers, or
anything using an immersion-type element,
even gas systems.
4 pole
Contactors
COIL
ITEM No. POLES VOLTAGE
3
24
263-1087
3
24
204-1249
3
120
149-1002
3
208/240
149-1001
3
208/240
149-1004
3
120
149-1005
3
208/240
149-1007
3
208/240
187-1186
3
208/240
539-1002
4
120
149-1008
4
208/240
149-1009
4
120
149-1010
4
208/240
149-1011
FULL RESIST.
LOAD LOAD
AMP AMP
30
40
40
50
30
40
25
35
30
40
40
50
40
50
40
50
50
65
30
40
30
40
40
50
40
50
More reliable and versatile than mechanical systems.
Protect heating elements from burnout due to low
water levels. Systems II and III can also automatically
refill the water tank to a preset level.
• 4" L x 2" W x 1 5 ⁄ 8 " H
• Includes instructions
(102mm x 51mm x 41mm)
System I:
Element Shut Down Only
For manual refill systems. Shuts off element when
water level falls below sensing probe.
Order individual components
Element
Must be used with contactor shown on this page.
1. No. 253-2000 120/240 volt control module
2. No. 253-2004 Water level sensing probe

(2 required)
Note: Must be used with contactor shown
on this page.
©2013 Franklin Machine Products
2
4
Element
Burner
Order individual components
FULL RESIST.
COIL
LOAD LOAD
ITEM No. POLES VOLTAGE AMP AMP
40
2
24
30
149-1126
40
2
120
30
149-1127
2
208/240
30
40
207-1009
1
System II:
Automatic Water Level
Control Only
Automatically opens and closes solenoid valve to
maintain proper water level in tank. Can also be
used on gas systems.
Contactors
1
2
Must be used with water
solenoid valve.
1. No. 253-2000 120/240 volt control module
2. No. 253-2004 Water level sensing probe

(2 required)
4. No. 107-1048 1 ⁄ 2 " NPT inlet faucet
Note: Must be used with water solenoid valve.
©2013 Franklin Machine Products
2
4
1
3
System III:
Element Shut Down and
Automatic Refill
Order individual components
A combination of System I and II, which offers the
most protection. Shuts off element when water is low
and automatically refills the tank.
MERCURY
CONTACTOR
No. 172-1103
• 208/240 volt coil
• 60 amp resistance load
• 1 pole
1. No.
2. No.

3. No.
4. No.
253-2000 120/240 volt control module
253-2004 Water level sensing probe
(2 required)
149-1019 Indicator light
107-1048 1 ⁄ 2 " NPT inlet faucet
Note: Must be used with contactor and water
solenoid valve. See this page for contactors.
Element
Must be used with
contactor shown on
this page.
Must be used with
water solenoid valve.
©2013 Franklin Machine Products
System Components
2 2 Probe
MERCURY
CONTACTORs
1 1 Control module
• 60 amp resistance load
No. 103-1044 24 volt coil, 3 pole
No. 103-1225 120 volt coil, 2 pole
For Water Solenoid
Valves, see page 197.
