GAS & ELECTRIC
infinite controls
1
2
Commercial-Duty
Robertshaw ®
Infinite Control Kits
3
Robertshaw ® Infinite Controls
Horizontal Palnut Mount†
• .187" diameter x 1" long
stem flat down
(5mm x 25mm)
D stem,
1. No. 204-1091 120 volt
1. No. 204-1092 240 volt
• .187" diameter x 1" long
stem flat up
(5mm x 25mm)
• Heavy-duty control
• Kit includes dial and hardware to replace
most controls
• 15 amp rating
• .187" diameter x 2 1 ⁄ 8 " long (54mm x 5mm)
double D breakaway stem
No. 250-1023 120 volt
No. 250-1024 240 volt
D stem,
No. 130-1083 Dial only
No. 130-1086 Dial insert only
No. 250-1033 120 volt
No. 250-1034 240 volt
INFINITE
CONTROL DIAL
No. 130-1087
• Flat up in “Off” position
• 2" (51mm) diameter
• Black plastic
Vertical Palnut Mount†
(5mm x 19mm)
• 15 amp rating
• .187" diameter x 2 1 ⁄ 8 " L (5mm x 54mm)
breakaway double D stem
• Kit includes white dial, dial insert
(No. 130-1086), palnut (No. 250-1025),
and hardware to replace most controls
Replacement Parts
1. No. 218-1007 120 volt
1. No. 218-1008 208/240 volt
• .187" diameter x 3 ⁄ 4 " long
stem flat down
ROBERTSHAW ® HEAVY-DUTY
INFINITE CONTROL KITS
D stem,
2. No. 228-1194* 120 volt
2. No. 228-1156* 208/240 volt
4-Way Screw MOUNT
• .187" diameter x 3 ⁄ 4 " long
stem flat up
(5mm x 19mm)
D stem, Infinite
Control Dial
D stem, No. 130-1010
• Flat is down in “Off” position
• 1 7 ⁄ 8 " (48mm) diameter
• Fits standard .187" (5mm) diameter D stem
• Black plastic with chrome face
3. No. 173-1042 120 volt
3. No. 173-1043 208/240 volt
3. No. 173-1063* 208/240 volt
• .187" diameter x 7 ⁄ 8 " long
stem flat down
(5mm x 22mm)
3. No. 194-1076 120 volt
3. No. 194-1077 208/240 volt
* B style infinite control that operates from 22%
on low rather than 5%
† Palnut not included
No. 250-1025 Infinite control palnut
520
EGO Infinite Controls
• .187" diameter x 7 ⁄ 8 " long
D stem, stem flat down
(5mm x 22mm)
No. 235-1122* Beige, 208 volt
No. 160-1270 Beige, 240 volt
No. 160-1265* Silver and white, 208 volt
* Stem flat up
Infinite
Control Dial
No. 130-1083
• Universal 4-way mounting
• 1 15 ⁄ 16 " (49mm) diameter
• Fits standard .187" (5mm) diameter D stem
• Black plastic with chrome face
