Robertshaw ® 5300 and 5210 Electric Thermostats( continued)
ITEM No.
TEMP. RANGE
THERMOSTATS
CAP. LENGTH BULB SIZE BRACKET
TYPE
DIAL INCLUDED COMMENTS REPLACEMENT
DIAL
S-TYPE( SPST, breaks on temperature rise, 30 amp resistive at 277 volt AC)
103-1221
60 ° to 250 ° F
48 "
3
⁄ 8 " x 4 1 ⁄ 2 "
# 1
Y
–
M
204-1090
100 ° to 200 ° F
12 "
3
⁄ 8 " x 4 3 ⁄ 32 "
# 7
N
G, I
–
180-1007
100 ° to 325 ° F
36 "
3
⁄ 16 " x 11 3 ⁄ 16 "
# 1
N
–
N
202-1152
100 ° to 450 ° F
36 "
3
⁄ 16 " x 8 3 ⁄ 8 "
# 5
Y
–
N
172-1066
150 ° to 450 ° F
48 "
3
⁄ 16 " x 11 5 ⁄ 8 "
# 1
N
–
N
229-1084
175 ° to 550 ° F
42 "
3
⁄ 16 " x 11 1 ⁄ 2 "
# 1
N
–
R
218-1251
200 ° to 400 ° F
18 "
3
⁄ 8 " x 4 7 ⁄ 8 "
# 1
N
–
Q
172-1063
200 ° to 400 ° F
24 "
3
⁄ 8 " x 5 1 ⁄ 8 "
# 1
N
–
Q
230-1001
200 ° to 400 ° F
48 "
5
⁄ 16 " x 7 1 ⁄ 2 "
# 1
N
–
Q
218-1111
200 ° to 400 ° F
60 "
5
⁄ 16 " x 7 "
# 1
N
–
Q
202-1128
200 ° to 450 ° F
36 "
3
⁄ 16 " x 10 "
# 5
N
–
L
202-1130
200 ° to 500 ° F
36 "
3
⁄ 16 " x 12 3 ⁄ 4 "
# 5
Y
–
L
SA-TYPE( model S with SPST auxiliary switch which breaks in“ Off” position)
218-1089
150 ° to 450 ° F
24 "
3
⁄ 8 " x 3 11 ⁄ 16 "
# 1
N
A
N
202-1008
150 ° to 450 ° F
36 "
1
⁄ 8 " x 23 3 ⁄ 16 "
# 5
N
A
N
202-1132
200 ° to 400 ° F
24 "
3
⁄ 16 " x 6 7 ⁄ 16 "
# 5
N
A
Q
218-1292
200 ° to 450 ° F
36 "
3
⁄ 16 " x 9 3 ⁄ 4 "
# 1
N
A
–
202-1131
200 ° to 450 ° F
36 "
3
⁄ 16 " x 10 "
# 5
N
A
L
SJ-TYPE( SPST, breaks on temperature rise with auxiliary switch, 30 amp at 277 volt AC)
173-1002
100 ° to 450 ° F
36 "
3
⁄ 16 " x 11 5 ⁄ 8 "
# 1
Y
A
N
173-1138
100 ° to 450 ° F
36 "
3 ⁄ 16 " x 11 5 ⁄ 8 "
# 1
N
–
N
228-1187
175 ° to 550 ° F
42 "
3
⁄ 16 " x 11 1 ⁄ 4 "
# 1
N
–
R
173-1035
200 ° to 375 ° F
20 "
3
⁄ 8 " x 5 3 ⁄ 4 "
# 1
N
A, D
Q
228-1193
300 ° to 700 ° F
36 "
3
⁄ 16 " x 12 1 ⁄ 4 "
# 1
Y
A
S
184-1072
300 ° to 700 ° F
72 "
3
⁄ 16 " x 11 3 ⁄ 4 "
# 1
N
A
S
No. 721-0804 Replacement screw
• 8-32 thread
SL-TYPE
194-1105
200 ° to 375 ° F
36 "
5
⁄ 16 " x 7 1 ⁄ 2 "
# 1
N
–
Aa
SP-TYPE( model S with positive“ Off” position)
170-1013
100 ° to 450 ° F
72 "
3
⁄ 16 " x 11 5 ⁄ 8 "
# 1
Y
–
N
202-1133
200 ° to 400 ° F
14 "
3
⁄ 16 " x 6 7 ⁄ 16 "
# 5
N
–
Q
250-1013
200 ° to 400 ° F
60 "
3
⁄ 8 " x 5 5 ⁄ 8 "
# 6
N
J
Q
160-1304
200 ° to 450 ° F
36 "
1
⁄ 8 " x 24 1 ⁄ 2 "
# 5
N
–
Ff
173-1034
300 ° to 375 ° F
24 "
1
⁄ 4 " x 8 1 ⁄ 2 "
# 1
N
D
–
170-1032
300 ° to 650 ° F
24 "
1
⁄ 4 " x 7 1 ⁄ 2 "
# 1
N
–
–
GAS & ELECTRIC
Legend for Comments
A With auxiliary switch B Screwdriver adjustment C Dipsealed D Has panel nut E Uni kit F 1 ⁄ 4 " stuffing box G 3 ⁄ 8 " stuffing box H Fiberglass cap shield I Pointer-type adjustment J 2 " break off shaft K Curved bulb
Legend for Replacement Dials
ITEM TEMP. No. RANGE
L 130-1001
1 to 10
M 130-1002
60 ° to 250 ° F
N 130-1004
100 ° to 450 ° F
O 220-1171
175 ° to 500 ° F
P 187-1101
200 ° to 500 ° F
Q 130-1007
200 ° to 400 ° F
R 130-1008
200 ° to 550 ° F
S 130-1009
300 ° to 700 ° F
T
168-1194
230 ° to 375 ° F
U 183-1142
100 ° to 200 ° F
V 130-1005
100 ° to 550 ° F
W 171-1106
250 ° to 600 ° F
X 501-1016
90 ° to 190 ° F
Y 180-1053
60 ° to 200 ° F
Z 227-1058
200 ° to 400 ° F
Aa 194-1106
200 ° to 375 ° F
Bb 229-1174
150 ° to 500 ° F
Cc 173-1153
200 ° to 450 ° F
Dd 130-1061
200 ° to 400 ° F
Ee 130-1003
100 ° to 200 ° F
Ff 160-1303
200 ° to 450 ° F
Replacement thermostats for specific equipment are listed by the manufacturer’ S name in the Parts section of this catalog.
see the manufacturers’ Cross Reference for Robertshaw ® numbers stamped on their controls.
