GAS & ELECTRIC
2
1
brass Reducing Bushings
Hex Bushings
1.
1.
1.
1.
1.
Robertshaw ® FD Type 1
Commercial Thermostat
Kits
• 3 ⁄ 8 " NPT inlets and outlets on the sides and rear
• 1 ⁄ 4 " or 3 ⁄ 16 " OD tubing outlet for pilot
• Universal 4-way mounting dial
• 54" capillary
• 3 ⁄ 16 " x 14 3 ⁄ 4 " bulb
No.
No.
No.
No.
No.
117-1026 1 ⁄ 4 " x 1 ⁄ 8 " NPT
117-1028 3 ⁄ 8 " x 1 ⁄ 4 " NPT
117-1024 1 ⁄ 2 " x 1 ⁄ 4 " NPT
117-1025 1 ⁄ 2 " x 3 ⁄ 8 " NPT
117-1027 3 ⁄ 4 " x 1 ⁄ 2 " NPT
Flush Bushings
Robertshaw ® BJWA
Commercial Thermostat Kits
No. 152-1008 FDTO throttling type
• Low (200°) to 550°F (dial is Fahrenheit only) Designed for use in commercial ovens and griddles.
Can be mounted in any of 4 manifold positions.
Kit will replace most BJ and BJWA commercial
thermostat installations.
Griddle thermostat kit
No. 152-1000
• 150° to 400°F (dial is Fahrenheit only)
• 1 ⁄ 4 " NPT outlet
• 36" capillary
• 3 ⁄ 16 " x 8" bulb
PLUG
No. 117-1354
• For plugging combination valves,
solenoid valves, and other gas
valv es with 1 ⁄ 8 " NPT outlet
• Brass
No. 152-1007 FDO snap throttle type
• 150° to 550°F (dial is Fahrenheit only)
2. No. 117-1033 3 ⁄ 8 " x 1 ⁄ 4 " NPT
2. No. 117-1030 1 ⁄ 2 " x 3 ⁄ 8 " NPT
2. No. 117-1032 3 ⁄ 4 " x 1 ⁄ 2 " NPT
Oven thermostat kit
• 250° to 550°F (dial is Fahrenheit only)
• 1 ⁄ 4 " NPT outlet
• 3 ⁄ 16 " x 11 5 ⁄ 8 " bulb
BJWA THERMOSTAT
No. 229-1160
• 100° to 450°F (38° to 232°C)
temperature range
• 3 ⁄ 8 " NPT rear outlet
• 36" capillary
• 3 ⁄ 16 " x 8 1 ⁄ 4 " bulb
No. 152-1001 48" capillary
No. 152-1009 72" capillary
OVEN CAPILLARY
BULB CLIP
No. 133-1485
• For oven and range thermostats with 3 ⁄ 16 " (5mm)
diameter capillary bulbs
• Used on gas and electric thermostats
• Holds bulb in desired position for calibration
• Black steel
BJWA THERMOSTAT CAPILLARY CLOTH
No. 166-1248
• 150° to 400°F temperature range
• ¼" NPT outlet
• 36" capillary
• 8 1 ⁄ 4 " L x 3 ⁄ 16 " OD bulb
• Knob not included (see No. 166-1245) No. 253-1445
• For insulating thermostat capillary tubes
• 600°F (316°C) maximum temperature rating
• 5 ⁄ 16 " (7mm) ID
• Woven black fiberglass
• Sold by the foot
Phone: [phone]
24-Hour Fax: [phone]
Stuffing Box Kit
No. 158-1100 Replacement kit
• 3 ⁄ 8 " NPT
• Fits all capillaries up to 3 ⁄ 8 " diameter bulb
• Nickel-plated brass
No. 158-1029 Reducing bushing
• Converts 1 ⁄ 4 " NPT stuffing box applications
to 3 ⁄ 8 " NPT
• Brass
Note: N
 o. 158-1100 is designed to replace
existing stuffing boxes.
Flanged
Nipple Kit
No. 158-1137
• 11 ⁄ 16 " wide narrow flange
• Used on narrow flange BJ thermostats
No. 117-1482 Face bushing
