Hardware & Maintenance
Hydraulic Door Closers
HYDRAULIC DOOR CLOSER
No. 124-1474
• #3 closer
• Surface mount
• Separate adjustments for closing and latching speeds
• For use on left- or right-hand doors
• For doors up to 165 lb (75kg)
• ¾" x 8 3 ⁄ 16 " (19mm x 208mm) mounting centers
• Includes parallel arm bracket and hardware
• Aluminum finish
Hydraulic Door Closers
• #4 closer
• Separate adjustments for closing and latching speeds
• For use on left- or right-hand doors
• For doors up to 165 lb (75kg)
• 3 ⁄ 4 " x 9 1 ⁄ 8 " (19mm x 232mm) screw centers
No. 134-1120 Aluminum finish
No. 134-1121 Dark brown finish
©2011 Franklin Machine Products
Parallel Arm Brackets
©2011 Franklin Machine Products
• Parallel arm brackets allow door closers to be mounted
as shown in drawing
No. 134-1009 Aluminum finish
No. 134-1008 Dark brown finish
Adjustable Door Closers
These heavy-duty closers are very versatile. They contain adjustments
for mounting in just about any situation.
• Closer is adjustable from #1 to #6
• For use on left- or right-hand doors
• ADA compliant at lower setting
• Separate adjustments for closing and latching speeds
• Adjustable backset control valve
• Includes parallel arm bracket
• 9 ⁄ 16 " x 11 1 ⁄ 8 " (14mm x 283mm) screw centers
No. 134-1118 Aluminum finish
No. 134-1119 Dark brown finish
No. 134-1125 Polished brass
Barrier-Free, Delayed Action Door Closers
• Opening force and closing speed can be adjusted to allow easy passage
• Closer is adjustable from 1 ⁄ 2 to #4
• Separate adjustments for the following: closing speed, closing delay, latching
speed, and backcheck control
• For use on left- or right-hand doors
• Includes parallel arm bracket and cover
• 9 ⁄ 16 " x 11 1 ⁄ 8 " x 1 1 ⁄ 8 " (14mm x 283mm x 29mm) screw centers
No. 134-1128 Aluminum finish
No. 134-1129 Dark brown finish
