Hardware & Maintenance
Latches, strikes, & Catches
hinges
Adjustable
Tension
Catch
Cabinet Latches and strikes
No. 134-1042
• 3 ⁄ 4 " x 3 1 ⁄ 8 " (19mm x 79mm)
• Tension is set with
adjusting screw
• Nickel-plated brass
No. 122-1216 1 7 ⁄ 8 " x 1 7 ⁄ 8 " (48mm x 48mm)

latch base dimension
• Includes flush strike, 1 ⁄ 8 " (3mm) offset strike,
and 3 ⁄ 8 " (10mm) offset strike
• 7 ⁄ 8 " (22mm) latch screw centers
• Chrome-plated
No. 122-1213 1 1 ⁄ 2 " x 1 1 ⁄ 2 " (38mm x 38mm)

latch base dimension
• Includes flush strike, 1 ⁄ 8 " (3mm) offset strike,
and 3 ⁄ 8 " (10mm) offset strike
• 11 ⁄ 16 " (17mm) latch screw centers
• Chrome-plated
Adjustable
Tension Catch
No. 134-1074
• 7 ⁄ 16 " x 2 3 ⁄ 8 " (11mm x 60mm)
• Tension is set with
adjusting screw
• Nickel-plated brass
Heat Resistant
edgemount Hinge
No. 123-1227
• Heavy-duty, can be used on heated cabinets
• 13 ⁄ 16 " (21mm) offset
• Offset is adjustable 3 ⁄ 16 " (5mm)
• 5" L x 15 ⁄ 16 " W (127mm x 24mm)
• 1 1 ⁄ 16 " (27mm) screw centers
• Chrome-plated solid brass
• CHG no. R42
• Kason no. 1216
Spring Kit
No. 123-1222
• Converts above hinge to spring-assisted
Magnetic
Cabinet Catch
Spring Catch and Strike
No. 124-1136
• For holding doors tightly closed
• Can be mounted vertically or horizontally
• 8 lb (4kg) pull
• 1" x 4" (25mm x 102mm)
• 3 3 ⁄ 8 " x 3 ⁄ 16 " (86mm x 5mm) screw centers on catch
• Adjustable tension
• Zinc-plated
No. 134-1077
• 30 lb (14kg) pull
• 3 1 ⁄ 8 " L x 9 ⁄ 16 " W x 1" D
(79mm x 14mm x 25mm)
• Zinc-plated steel
Magnetic
Cabinet Catches
No. 134-1075 Plastic housing
• 12 lb (5kg) pull
Magnetic Door Catches
No. 134-1076 Steel housing
• 20 lb (9kg) pull
• Zinc-plated steel
No. 175-1063 2 L x
W (57mm x 10mm)
No. 204-1113 1 9 ⁄ 16 " L x 3 ⁄ 8 " W (40mm x 10mm)
1
⁄ 4 "
⁄ 8 "
3
Phone: [phone]
24-Hour Fax: [phone]
A
Pivot Hinges
• 3 5 ⁄ 16 " (84mm) high
• Nickel-plated steel
No. 123-1199 1 5 ⁄ 8 "
No. 123-1198 1 7 ⁄ 8 "
(41mm)
(48mm)
“A” dimension
“A” dimension
