Hardware & Maintenance
bullet FEET & ACCESSORIES
CORNER BRACKET
No. 135-1260
• For 1 5 ⁄ 8 " OD round tubing
• Provides strong and secure undershelf support
Flanged Foot BULLET FOOT
No. 119-1104
• For 1" (25mm) square tubing
• Adjustable from 3 ⁄ 4 " to 1 1 ⁄ 2 "
• 1 3 ⁄ 16 " flange diameter
• Nickel-plated No. 119-1101
• For 1 5 ⁄ 8 " OD tubing
• 1 1 ⁄ 2 " to 2 5 ⁄ 8 " height adjustment
• 2000 lb load capacity
• Stainless steel
(19mm to 38mm)
Stainless Steel Tubing
• 10' long
• Satin finish
No. 135-1189 1" OD
No. 135-1217 1 5 ⁄ 8 " OD
Note: 1
 0' lengths ship by truck. Can be cut at your
request. Cutting charges apply.
1 3 ⁄ 4 "
2 ⁄ 2 "
1
Kick Plate Spring Clamp
FLANGED BULLET FOOT BULLET FOOT
No. 119-1100
• For 1 5 ⁄ 8 " OD tubing
• 1 1 ⁄ 2 " to 2 5 ⁄ 8 " height adjustment
• 3 1 ⁄ 2 " flange diameter
• 2000 lb load capacity
• Stainless steel with satin finish No. 119-1103
• For 1 5 ⁄ 8 " OD tubing
• 1 1 ⁄ 2 " to 2 1 ⁄ 2 " height adjustment
• 2000 lb load capacity
• Black thermoplastic
Wide flange
bullet foot bullet foot
No. 119-1063
• For attaching kick plate to equipment leg
• Fits snugly on 1 1 ⁄ 4 " pipe, 1 1 ⁄ 2 ", 1 5 ⁄ 8 ", or
2" OD tubing
Wide Flange Bullet Foot
No. 119-1062
• For 1 5 ⁄ 8 " OD round tubing
• 11 ⁄ 32 " holes on 2 1 ⁄ 2 " centers
• 1 1 ⁄ 2 " to 2 3 ⁄ 4 " height adjustment
• 3 1 ⁄ 2 " flange diameter
• Stainless steel
326
No. 119-1095
• For 1 5 ⁄ 8 " OD tubing
• 11 ⁄ 32 " holes on 2 1 ⁄ 2 "
hole centers
• 1 1 ⁄ 2 " to 4 1 ⁄ 2 " height
adjustment
• 3 1 ⁄ 2 " flange diameter
• 2000 lb load capacity
• Stainless steel with
satin finish
No. 119-1093
• For 1 5 ⁄ 8 " OD tubing
• 1 1 ⁄ 2 " to 4 1 ⁄ 2 " height
adjustment
• 2000 lb load capacity
• Stainless steel
