REFRIGERATION
CAM LIFT HINGE Hinge Hinges
No. 123-1238
• Commonly used on Kolpak ® and Vollrath ®
• Flush mount
• Satin chrome-plated
• CHG no. W55-1000 No. 123-1080
• 1 1 ⁄ 8 " (29mm) offset
• Chrome-plated
• Premco nos. PR6, PR6H1- 1 ⁄ 8 • Chrome-plated
• Kason no. 1070
HINGES
No. 123-1076 Flush
No. 123-1075 7 ⁄ 8 " (22mm) offset
No. 123-1074 1 1 ⁄ 8 " (29mm) offset
6" (152mm)
6 1 ⁄ 16 "
6 15 ⁄ 16 "
3"
(176mm)
(76mm)
6 1 ⁄ 8 "
(154mm)
3 1 ⁄ 16 "
(78mm)
2"
(51mm)
(156mm)
3 1 ⁄ 16 "
(78mm)
2"
(51mm)
For important information on how to measure offsets, see the front of the Refrigeration section.
Hinge Hinge
No. 123-1082
• 1 1 ⁄ 8 " (29mm) offset
• Chrome-plated
• Kason no. 1070A No. 123-1078
• 1 1 ⁄ 8 " (29mm) offset
• Stainless steel
• Polar nos. 105, 411
6 1 ⁄ 4 "
6 1 ⁄ 4 "
(159mm)
2"
2 5 ⁄ 16 "
(51mm)
(59mm)
Phone: [phone]
3"
(76mm)
24-Hour Fax: [phone]
(159mm)
1 3 ⁄ 4 "
(159mm)
