PLUMBING
Drip Trays
1
Flanged Drop-In Drip
Trays with drain
CounterTop Drip Trays
with drain
• 3 ⁄ 8 " flange
• 3 ⁄ 4 " deep
• 1 ⁄ 2 " x 2" NPS brass drain
• Stainless steel trough
• 1 ⁄ 2 " x 2" NPS brass drain
• Stainless steel trough
No. 102-1088 14 7 ⁄ 8 " x 5 3 ⁄ 8 " x 3 ⁄ 4 " D
No. 102-1090 24" x 5 3 ⁄ 8 " x 3 ⁄ 4 " D
No. 102-1091 Fits 14 7 ⁄ 8 " x 5 1 ⁄ 2 " cut-out
No. 102-1093 Fits 24 1 ⁄ 4 " x 5 1 ⁄ 2 " cut-out
Replacement parts
No. 102-1089 Grid only for drip tray

(No. 102-1088)
No. 102-1117 Grid only for drip tray

(No. 102-1090)
2
Replacement parts
No. 102-1089 Grid only for drip tray

(No. 102-1091)
No. 102-1117 Grid only for drip tray

(No. 102-1093)
COUNTERTOP DRIP TRAYs
WITHOUT DRAIN
• Stainless steel trough with removable
white plastic grid
• Includes rubber feet
1. No. 102-1187 8" L x 5 1 ⁄ 2 " W x ¾" D
(203mm x 140mm x 19mm)

For Germicidal Drip Tray Strips,
see page 189.
2. No. 102-1188 15" L x 5 3 ⁄ 8 " W x ¾" D
(381mm x 137mm x 19mm)

water station Sinks
Water Station by Fisher Water Station by T&S Brass
No. 113-1012
• 10 1 ⁄ 8 " W x 8 1 ⁄ 2 " D overall size
• 3 1 ⁄ 4 " deep
• 11 ⁄ 16 " diameter hole for glass filler shank
• 3 ⁄ 4 " NPS x 1 3 ⁄ 4 " drain
• Stainless steel
• Fisher no. 1400-0000 No. 110-1090
• 10 1 ⁄ 2 " W x 12 1 ⁄ 2 " D overall size
• 4 1 ⁄ 2 " x 10" x 1 1 ⁄ 2 " deep drainage area
• Drainage area is 2 3 ⁄ 4 " from riser hole
• 7 ⁄ 8 " diameter hole for glass filler shank
• 1 1 ⁄ 4 " OD x 4" long drain tailpiece
• Stainless steel
• T&S no. B1231
Phone: [phone]
24-Hour Fax: [phone]
Water Station
No. 117-1138
• 12" W x 14" D overall size
• 8 3 ⁄ 4 " x 8 3 ⁄ 4 " x 3" deep drainage area with grid
• Drainage area is 2" from riser hole
• 7 ⁄ 8 " diameter hole for glass filler shank
• Includes 1 ⁄ 2 " NPS drain
• Stainless steel
