PLUMBING
Water Hoses & Disconnects
PLUMBING
1
2
3
SWIRL HOSE™ water Suppy lines WITH STREET ELBOWS by DORMONT ®
• For connecting foodservice equipment to water supply such as ice machines, coffee makers, etc.
• 48 " long( extended)
• 160 ° F maximum working temperature
• 100 PSI
• Includes street elbow
• Spiral polyurethane tubing with brass fittings
1. No. 117-1461 1 ⁄ 4 " ID hose
• 1 ⁄ 4 " NPT male x 1 ⁄ 4 " NPT female fittings
• Dormont no. 71-1114-48
1. No. 117-1462 3 ⁄ 8 " ID hose
• 3 ⁄ 8 " NPT male x 3 ⁄ 8 " NPT female fittings
• Dormont no. 72-2124-48
1. No. 117-1463 1 ⁄ 2 " ID hose
• 1 ⁄ 2 " NPT male x 1 ⁄ 2 " NPT female fittings
• Dormont no. 73-3134-48
2. No. 117-1464 1 ⁄ 2 " ID hose
• 1 ⁄ 2 " NPT male fittings
• Includes quick disconnect
• Dormont no. 73-3135-48
3. No. 117-1465 3 ⁄ 8 " ID hose
• 1 ⁄ 4 " NPT male x 1 ⁄ 4 " NPT female fittings
• Includes 1 ⁄ 4 " flare fitting( No. 117-1460)
• Dormont no. 71-1118-48
Flare Fitting for 1 ⁄ 4 " ID hose
No. 117-1460
• 1 ⁄ 4 " NPT male x 1 ⁄ 4 " female flare fitting
• Dormont no. LF90-1112
WATER HOSES by DORMONT ®
Can be used as a water supply hose for commercial steamers, combination ovens, and equipment on casters. Features kink-resistant tubing.
• 3 ⁄ 4 " female garden hose thread x 3 ⁄ 4 " female garden hose thread
• Maximum temperature 140 ° F
• 125 PSI maximum pressure
• Clear PVC with woven nylon and polyester underbraiding
No. 117-1380 48 " long
• Dormont no. 3 / 4CSC-P-HH48
No. 117-1381 60 " long
• Dormont no. 3 / 4CSC-P-HH60
QUICK DISCONNECTS by DORMONT ®
• Stainless steel
No. 117-1458 ¼ " NPT
• For ¼ " NPT Swirl Hose™ water supply line( No. 117-1461)
• Dormont nos. LFW25QD, W25QD
No. 117-1459 ½ " NPT
• For ½ " ID Swirl Hose™ water supply line( Nos. 117-1463 and 117-1464)
• Dormont nos. LFW50QD, W50QD
No. 117-1457 3 ⁄ 8 " NPT
• For Swirl Hose™ water supply line( No. 117-1462)
• Dormont nos. LFW37QD, W37QD
HOT WATER HOSE by T & S BRASS
No. 111-1316
• For combination ovens, kettles, steamers, and any other equipment requiring a water line
• 60 " long
• ½ " NPT x ½ " NPT male fittings
• Withstands temperatures to 175 ° F
• 0 – 1000 PSI
• 360 ° rotation welded fitting connections
• Used with quick disconnect( No. 111-1317)
• Blue rubber-coated stainless steel
• T & S no. HW2C60
QUICK DISCONNECT by T & S BRASS
No. 111-1317
• ½ " NPT female inlet and outlet
• Used with hot water hose( No. 111-1316)
• Stainless steel
• T & S no. AW5C
Co2 Cartridge accessories
Slotted-Type Disconnect
No. 104-1068
• For gas
• 2 slots
• 1 ⁄ 4 " male flare
• Plastic
